Jyoti Steels is a prominent Inconel 601 Wire manufacturer and supplier company in Mumbai, India. We are expert in providing high-performance nickel-based alloy wires for meeting the rigorous requirements of aerospace, thermal processing, and chemical handling industries. Our Inconel 601 Wire is highly renowned for its excellent heat, oxidation, and corrosion resistance. With accuracy in manufacturing, rigorous quality checking, and prompt delivery, Jyoti Steels has established a reputation for dependability and excellence, catering to clients within India as well as globally.
Inconel 601 Wire contains mainly Nickel (58–63%), Chromium (21–25%), and Iron (balance), with Aluminum (1–1.7%), Carbon (max 0.10%), Manganese (max 1%), and Silicon (max 0.5%). It has superior mechanical properties, such as tensile strength of approximately 550 MPa, yield strength of 205 MPa, and elongation of 30%. Physical properties are a density of 8.11 g/cm³ and a melting point of 1320–1370°C. These qualities render Inconel 601 Wire well suited for applications involving high temperatures, mechanical stress, and corrosive or oxidizing conditions.
| Specifications | ASTM B166 ASME SB166, AMS | |
|---|---|---|
| SB 166 UNS N06601 Wires Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Alloy 601 Wires Length | 100 mm TO 6000 mm, customizable | |
| ASTM B166 UNS N06601 Wires Diameter | 10 mm To 100 mm or as per client requirement | |
| 2.4851 Alloy 601 Wires Main Types |
|
|
| Alloy 601 UNS N06601 Wires Density | 8.89 g/cm3 | |
|
580-750 | |
|
as standard | |
|
28-30 | |
| Surface | Polished bright, Smooth | |
| Inconel N06601 Wires Technique | Cold Rolled, hot rolled | |
| Din 2.4851 Wires Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Inconel 601 welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| SB 166 UNS N06601 wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including |
|
|
| Sample | Free sample | |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
| Grade | C | Mn | Si | Cu | S | Cr | Fe | Ni | N |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 1.00 max | 0.015max | 21.00 – 25.00 | bal | 58.0-63.0 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Wire in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Wire is widely utilized in high-temperature and corrosive applications owing to its higher oxidation resistance and mechanical stability. It finds general application in heat treatment fixtures, furnace heating elements, exhaust systems, and thermal processing equipment. In the chemical industry, it’s particularly suited for catalyst support grids and reactor linings. Aerospace and automotive industries employ this wire in high-heat parts like turbine exhaust ducts and heat shields. Its oxidation resistance to 1200°C also qualifies it for use in radiant tubes, protection tubes for thermocouples, and other long-term thermal cycling-exposed applications.
