Jyoti Steels is a leading supplier and manufacturer of Titanium Gr 2 Tubing in Mumbai, India, delivering high-quality corrosion-resistant tubing solutions for critical industrial applications. Jyoti Steels is well known for its reliability and conformance to international standards and offers Titanium Grade 2 tubing with excellent formability, moderate strength, and outstanding corrosion resistance. With cross-industry application in the chemical, aerospace, marine, and medical sectors, timely delivery, and bespoke solutions, the firm is a reputed name in the market for titanium products both locally and globally.
Titanium Gr 2 Tubing is made up of Titanium (Ti) ≥ 99.2%, with minute quantities of Oxygen ≤ 0.25%, Iron ≤ 0.30%, Carbon ≤ 0.08%, Nitrogen ≤ 0.03%, and Hydrogen ≤ 0.015%. The alloy provides a tensile strength of about 344 MPa, a yield strength of 275 MPa, and elongation of around 20%. It possesses a density of 4.51 g/cm³ and a melting point of about 1665°C. All these characteristics render the tubing light, weldable, and easily shapeable, as well as very resistant to corrosion in oxidizing and mildly reducing conditions, such as in marine and chemical processing environments.
| Specifications | ASTM B338 |
|---|---|
| ASTM B338 Grade 2 Tubes Size | 15 NB to 150 NB IN |
| Cp Grade 2 Tubing Wall Thickness | .035″ -.095′, (special wall thicknesses available) |
| Specialized in | Large Diameter Size |
| ASME SB 338 Gr 2 Tubing Type | Seamless / ERW / Welded / Fabricated / Hollow |
| Ti Cp Grade 2 Tubes Schedule | SCH5, SCH10, SCH40, STD, SCH80, SCH160 |
| ASME SB 338 Grade Tubes Condition | Hot-Finished, Annealed, Cold-Drawn, Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Titanium Grade 2 Tubes Form | Coiled, Condenser, Straight, Heat-Exchanger, Capillary, U-Tube, Boiler, Square, Rectangular, Round, Hydraulic |
| SB 348 Gr 2 Tubes Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded. |
| Marking | All ASTM B338 Gr2 Titanium Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2 |
| Element | Titanium | Nitrogen | Carbon | Hydrogen | Iron | Oxygen | Residuals (each) | Residuals (total) |
|---|---|---|---|---|---|---|---|---|
| % | Balance | 0.03 max | 0.08 max | 0.015 max | 0.30 max | 0.25 max | 0.1 max | 0.4 max |
| 0.2% Proof Stress | Tensile Strength | Elongation | |
| MPa | MPa | % | |
| Annealed | 275-450 | 345 | 20 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Gr 2 Tubing in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 2 Tubing has vast applications in various industries due to its superior corrosion resistance and formability. It is employed in heat exchangers, condensers, and reactor tubing in the chemical processing industry. Aerospace industry utilizes it for hydraulic lines, fuel systems, and structural tubing. It is employed in shipbuilding and seawater desalination in the marine industry. It is also widely utilized in biomedical applications like surgical tools and implantable devices because of its biocompatibility. In addition, it is used in power plants, pulp and paper mills, and electroplating equipment for the treatment of corrosive media.
