Jyoti Steels is a renowned manufacturer and exporter of Titanium Forged Fittings in Mumbai, India. It is specialized in manufacturing high-grade forged fittings catering to the aerospace, marine, chemical, and medical industries. Jyoti Steels maintains a high standard of quality in all its products and is well known for excellence. All its fittings are ensured to be durable, strong, and performance-driven, conforming to international standards. Their titanium forged fittings are capable of enduring harsh conditions and are renowned for their corrosion resistance, which makes them suitable for severe applications in hostile environments.
Titanium Forged Fittings mainly comprise Titanium, with alloys such as Ti-6Al-4V comprising about 90% titanium, 6% aluminum, and 4% vanadium, with iron ≤ 0.3%, oxygen ≤ 0.2%, and carbon ≤ 0.08%. These fittings have high tensile strength of 895 MPa and yield strength of 830 MPa with 10% elongation. Titanium forged fittings possess low density of 4.43 g/cm³ and a melting point range of 1604°C to 1660°C and offer better strength-to-weight ratio, corrosion resistance, and excellent thermal stability under extreme conditions.
Specifications : ASTM B381 / ASME SB381
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Titanium Gr. 2 Titanium Gr. 5
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Forged Fittings find extensive use in aerospace engineering for aircraft components, fuel systems, and hydraulic systems, where lightness and strength are a must. In the marine sector, they are utilized in seawater systems, shipbuilding, and offshore use for their superior corrosion resistance. They are also of prime importance in chemical processing industries, where they are utilized in reactors, pressure vessels, and piping systems. In medicine, titanium forged fittings are employed in implants and surgical equipment because they are biocompatible. They also find critical applications in power generation, motor vehicles, and sporting goods production.
