Jyoti Steels is a leading manufacturer and supplier of Inconel 600 Stud Bolts based in Mumbai, India. It specializes in the delivery of high-performance industrial fasteners and is renowned for providing superior quality Inconel 600 Stud Bolts that provide outstanding resistance to heat, oxidation, and corrosion. With advanced manufacturing facilities and strict compliance with international standards, the company caters to a large variety of industries with reliable and durable solutions for tough applications. Jyoti Steels is relied upon for precision engineering, prompt delivery, and customer-orientated service in local as well as global markets.
Inconel 600 Stud Bolts mainly contain Nickel (72.0%), Chromium (14.0–17.0%), and Iron (6.0–10.0%) with small additions of Manganese (≤1%), Silicon (≤0.5%), and Carbon (≤0.15%). These bolts show superior mechanical properties with tensile strength of approximately 655 MPa, yield strength of 310 MPa, and elongation of about 45%. The physical characteristics are a density of 8.47 g/cm³, a melting point of 1354–1413°C, and good electrical and thermal conductivity. All these properties render Inconel 600 Stud Bolts ideal for high-temperature and high-stress applications.
| Specifications | ASTM A166 / ASME A166 |
| Standard | DIN, ISO ,JIS ,GB, IS, BS, ASTM and all International Standards |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Length | 3 mm – 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc. |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Treatment | Passivation /plain |
| Others Factor | OEM, ODM, ±0.03MM tolerance |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
| Packing | IN BULK: carton, pallet, Small Boxes or customer request |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 Stud Bolts find extensive applications in petrochemical, aerospace, power generation, and marine engineering industries. Their high corrosion and heat resistance properties also qualify them for applications in heat exchangers, reactors, furnace parts, gas turbines, and exhaust systems. They find application in chemical plants and nuclear reactors as well where mechanical integrity during extreme conditions is essential. Their reliability and durability also make them suitable for applications with high-pressure steam, seawater exposure, and other corrosive industrial environments.
