Jyoti Steels, Mumbai, India, is a reliable manufacturer and supplier of high–quality Inconel 601 Stud Bolts, offering fastening solutions to industries that function in harsh environments. Renowned for their accurate engineering and dedication to quality, Jyoti Steels supplies products that conform to international standards and function excellently in corrosive and high-temperature environments. Their Inconel 601 Stud Bolts find extensive applications in petrochemical, power, aerospace, and marine industries. With effective service, technical know-how, and customer-oriented focus, Jyoti Steels provides reliable delivery and durable performance for challenging industrial uses.
Inconel 601 Stud Bolts consist mainly of Nickel (58.0–63.0%), Chromium (21.0–25.0%), and Iron (balance), with Aluminum (1.0–1.7%), Carbon (≤0.10%), Manganese (≤1.0%), Silicon (≤0.5%), Sulfur (≤0.015%), and Copper (≤1.0%). These bolts have a tensile strength of around 600 MPa, yield strength of 275 MPa, and elongation of 30–35%. They have a density of 8.11 g/cm³ and a melting point between 1360–1411°C, such that they retain structural integrity even in the face of extreme temperatures and corrosive conditions. These chemical and physical properties make them superior in their resistance to oxidation, thermal fatigue, and carburization.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Stud Bolts find extensive usage in applications that require outstanding corrosion and thermal resistance. They find application in thermal processing sectors in furnaces, radiant tubes, and heat treatment equipment. They are utilized in boiler assemblies, gas turbines, and exhaust systems by power generation plants. The chemical sector uses them for reactor vessels and piping systems that handle corrosive materials. Aerospace applies them in engine and exhaust components. Marine sectors utilize their seawater corrosion resistivity. Their resistance to corrosion and hardness qualify them for application in pollution control, food processing, and petrochemical facilities.
