Jyoti Steels is a renowned Inconel 617 Stud Bolts manufacturer and supplier located in Mumbai, India, which provides high-quality fasteners for harsh temperature and corrosive conditions. Our Inconel 617 Stud Bolts are designed for sustained performance and structural strength in high-stress applications in the power, petrochemical, and aerospace industries. With a focus on precision manufacturing, global quality standards, and quality service, Jyoti Steels provides reliable fastening solutions to clients throughout India and the world, delivering both durability and timely delivery for mission-critical operations.
Inconel 617 Stud Bolts consist mostly of Nickel (44.5–60%), Chromium (20–24%), Cobalt (10–15%), and Molybdenum (8–10%), with small additions of Aluminum (0.8–1.5%), Carbon (max 0.05%), Iron, and Silicon. These bolts have very good mechanical properties such as tensile strength of around 540 MPa, yield strength of around 270 MPa, and elongation of 30%. They have a density of 8.36 g/cm³ and a melting range of 1330–1380°C. Inconel 617 is very resistant to oxidation, carburization, and creep and is very suitable for use over long periods in high-temperature and chemically aggressive environments.
Standard ASTM B168, B166 / ASME SB168, SB166
Dimensions ANSI B18.2.1, DIN 931,DIN 933, ISO 4014, ISO 4017,BS 1768, BS1768, IFI 115
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Size M02 to M160
Length 3 mm to 200 mm
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 617 Stud Bolts find extensive application in high-pressure, high-temperature conditions where mechanical properties and corrosion resistance are critical. In power plants, they are employed in heat recovery systems, gas turbines, and nuclear usage. In the aerospace industry, they hold components in combustion chambers and high-temperature ducts. The chemical and petrochemical industries apply these bolts to reactors, reformers, and piping systems in contact with corrosive gases. Their resistance to oxidation, carburization, and thermal fatigue makes them suitable for furnaces, heat exchangers, and industrial gas processing equipment. These bolts provide safe fastening in the most severe service conditions.
