Jyoti Steels is a reliable producer and supplier of Titanium Grade 2 Pipe Fittings in Mumbai, India, supplying high-quality corrosion-resistant solutions for critical industrial use. Being well known for reliability and international standards compliance, Jyoti Steels supplies Titanium Gr 2 pipe fittings with superior formability, moderate strength, and superior resistance to different corrosive conditions. These fittings find extensive applications in chemical processing, marine, and medicine industries, and Jyoti Steels provides precise manufacturing and on-time delivery to address the changing needs of India-based as well as global clients.
Titanium Gr 2 Pipe Fittings are made of pure Titanium (Ti) ≥ 99.2%, trace amounts of which are Iron (Fe) ≤ 0.30%, Oxygen (O) ≤ 0.25%, Carbon (C) ≤ 0.08%, Nitrogen (N) ≤ 0.03%, and Hydrogen (H) ≤ 0.015%. They provide tensile strength of 344 MPa, yield strength of 275 MPa, and elongation of 20%. Having a density of 4.51 g/cm³ and melting point of 1665°C, Titanium Gr 2 also exhibits excellent weldability and corrosion resistance in oxidizing and mildly reducing environments. These features render it perfect for use in durability, biocompatibility, and lightweight performance applications.
Specifications : ASTM B363 / ASME SB363
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Titanium Gr. 2
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Titanium Gr 2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Gr 2 Pipe Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 2 Pipe Fittings are extensively used in different industries for their strength, corrosion resistance, and light weight. In chemical processing, they are employed in seawater, acid, and chlorine-containing piping systems. They find applications in seawater cooling, ballast systems, and offshore platforms in the marine industry. The medical industry employs them due to their biocompatibility in surgical equipment and orthopedic implants. They are designed for use in desalination facilities, where power generation and aerospace applications require corrosion resistance and high reliability. They are used in applications where long-term performance and low maintenance are essential in harsh conditions.
