Jyoti Steels is a well-known Mumbai -based manufacturer and supplier of Titanium Gr 5 Pipe Fittings reputed for providing industry–leading titanium solutions for high-performing industrial demands. With their commitment to quality, accuracy, and compliance with international standards, Jyoti Steels has been serving various industries like aerospace, marine, chemical, and oil & gas. The firm provides guaranteed supply, corrosion-free products, and economic solutions, making it a desired supplier of robust and light-weight titanium fittings that function exceptionally well under harsh conditions.
Titanium Gr 5 Pipe Fittings consist of around 90% titanium, 6% aluminum, and 4% vanadium, along with trace impurities such as iron ≤ 0.3%, oxygen ≤ 0.2%, and carbon ≤ 0.08%. This alloy provides a high strength-to-weight ratio, with tensile strength of approximately 895 MPa, yield strength of approximately 830 MPa, and elongation of approximately 10%. It has a density of 4.43 g/cm³ and a melting point of 1604–1660°C. These fittings have excellent corrosion resistance, especially in seawater and aggressive chemical environments, and retain mechanical integrity over a broad temperature range.
| Standard | ASTM B366 / ASME SB366 |
| Dimensions | ANSI B16.9, B16.25, B16.28, MSS-SP-43, MSS-SP-48, MSS-SP-59 |
| Size | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Type | Seamless / Welded(100% X-Ray Welded) / Fabricated |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| (0.2%Offset) Yield Properties | Melting Point | Density | Tensile Properties | Elongation % |
|---|---|---|---|---|
| MPa – 880, Psi – 128000 , | (2970 °F) 1632 °C | 4.43 g/cm3 | MPa – 950, Psi – 138000 | 14 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Gr 5 Pipe Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 5 Pipe Fittings find widespread applications in aerospace in hydraulic and structural components because of their light weight and strength. In marine environments, they are used in desalination plants and shipbuilding where corrosion resistance is a major factor. They are utilized in the chemical processing industry for piping systems that carry corrosive fluids. In the manufacture of medical equipment, they are well suited for bio-compatible applications. They are also used in power generation, particularly in heat exchangers and condensers, and in offshore oil and gas facilities where they are required to be robust and withstand harsh conditions.
