Jyoti Steels is one of the prominent makers and providers of Titanium Gr 2 Sheet and Plate in Mumbai, India, which has a reputation for supplying high-grade, corrosion-resistant titanium products that can be used in numerous industrial applications. With a penchant for precision engineering, global standards conformance, and customer satisfaction, Jyoti Steels provides Titanium Grade 2 sheets and plates that are superior in formability, weldability, and strength. Supplying industries like aerospace, chemical processing, medical, and marine industries, the company provides dependable supply and performance-based solutions both at domestic and global levels.
Titanium Gr 2 Sheet and Plate is made up of Titanium (Ti) ≥ 99.2%, with limtations as follows: Oxygen ≤ 0.25%, Iron ≤ 0.30%, Carbon ≤ 0.08%, Nitrogen ≤ 0.03%, and Hydrogen ≤ 0.015%. This commercially pure titanium provides a tensile strength of around 344 MPa, yield strength of 275 MPa, and an elongation of around 20%. The density is 4.51 g/cm³ and the melting point is around 1665°C. These plates and sheets provide excellent corrosion resistance in oxidizing and chloride-containing environments, good ductility, and excellent weldability, which makes them very suitable for structural and fabrication applications.
| Specifications | : | ASTM / ASME SB265 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 2 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 2 Sheet and Plate finds extensive application in a variety of industries owing to its corrosion resistance and strength-to-weight ratio. In aerospace, it is employed for aircraft skins, ducts, and frames. In chemical processing, it finds application in tanks, heat exchangers, and piping systems. The marine industry applies it in desalination plants, shipbuilding, and offshore structures. It is also applied in medical devices, prosthetics, and surgical equipment because of its biocompatibility. It is also used in power generation, pulp and paper, and electroplating industries where resistance to harsh media and durability are essential.
