Jyoti Steels is a top-notch manufacturer and supplier of Titanium Grade 5 Sheet and Plate in Mumbai, India, supplying premium–grade materials designed for high-performance industrial uses. With sophisticated manufacturing facilities and a focus on global standards, Jyoti Steels offers Titanium Gr 5 (Ti-6Al-4V) sheets and plates renowned for their exceptional strength-to-weight ratio, high corrosion resistance, and heat resistance. All of these products find vital applications in aerospace, naval, medical, and chemical industry. Jyoti Steels provides assured consistency, timely shipments, and customer-specific solutions meeting the stringent expectations of national as well as worldwide customers.
Titanium Gr 5 Sheet and Plate contains Titanium (Ti) ~90%, Aluminum (Al) 6%, and Vanadium (V) 4%. It possesses superior mechanical properties with tensile strength of approximately 895 MPa, yield strength of about 828 MPa, and elongation of 10–15%. The density of the alloy is 4.43 g/cm³ and melting point is 1660°C. Its physical properties also comprise good thermal conductivity (~6.7 W/m·K) and superior corrosion resistance in oxidizing and chloride-containing environments. These characteristics render Gr 5 sheet and plate ideal for structural and high-stress applications that demand durability, strength, and low weight.
| Specifications | : | ASTM / ASME SB265 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 5 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 5 Sheet and Plate is commonly applied in aerospace parts such as fuselage panels, engine components, and landing gear owing to its high strength and light weight. In marine environments, it is perfect for offshore structures and shipbuilding parts exposed to saltwater. The medical sector employs it in surgical instruments, dental implants, and orthopedic plates because of its biocompatibility. It is applied in automotive, power generation, and chemical processing equipment where temperature stability and resistance to corrosion are critical. Such sheets and plates play a critical role in sectors requiring high performance and durability.
