Jyoti Steels is a reliable producer and distributor of Inconel 625 Bars in Mumbai, India, providing high-quality nickel-based alloy bars renowned for their superior strength and corrosion resistance. Inconel 625 finds extensive applications in industries where there is a need for toughness under harsh temperatures and aggressive conditions. Our bars are manufactured in accordance with international standards like ASTM B446 to provide quality and reliability. Jyoti Steels provides a wide range of customers in chemical processing, marine, aerospace, and power generation industries with precision-manufactured Inconel 625 bars for challenging uses.
Inconel 625 Bars consist of Nickel (58% min), Chromium (20–23%), Molybdenum (8–10%), Niobium + Tantalum (3.15–4.15%), and Iron (balance) along with minute quantities of Carbon (max 0.10%), Manganese (max 0.50%), and Silicon (max 0.50%). These bars have excellent mechanical properties such as tensile strength of approximately 827 MPa, yield strength of 414 MPa, and elongation of 30–35%. The density is 8.44 g/cm³ and the melting point is between 1290°C and 1350°C. Inconel 625 has superior resistance to oxidation, pitting, crevice corrosion, and chloride-induced stress corrosion cracking.
| Specifications | : | ASTM B446 / ASTM SB446 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 5 mm To 500 mm |
| Diameter | : | 0.1 mm to 100 mm |
| Length | : | 100 mm To 3000 mm Long & Above |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | Cu | S | Fe | Mo | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | – | 0.15 min | 5.0 max | – | 58.0 min | 20.0–23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1.350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Bars in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Bars find applications in a wide range of high-performance applications because of their superior strength and corrosion resistance. In the aerospace sector, they are applied in jet engine parts, turbine blades, and exhaust systems. Marine uses involve offshore platforms, seawater piping, and heat exchangers. In chemical processing, Inconel 625 is used in reactors, vessels, and tubing systems handling severe acids and alkalis. The bars are employed in nuclear power systems, pollution control devices, and oil & gas exploration equipment, where reliability and resistance to harsh environments are essential.
