Jyoti Steels in Mumbai, India, is a reputable manufacturer and supplier of Inconel 800 Bars in the form of high-quality alloy bars that are capable of delivering superior performance in high-temperature and corrosive conditions. With superior manufacturing technology and strict compliance with international standards, Jyoti Steels deals with a number of industries such as chemical processing, power generation, petrochemicals, and aerospace. Renowned for accuracy, consistency, and timely delivery, the company’s Inconel 800 bars are designed to stay strong and stable under thermal stress, which suits them well for high-performance industrial applications.
Inconel 800 Bar is a nickel-iron-chromium alloy with superior resistance to oxidation and carburization at high temperatures. Its chemical composition consists of Nickel (Ni) 30–35%, Chromium (Cr) 19–23%, Iron (Fe) balance, Aluminum (Al) 0.15–0.60%, Titanium (Ti) 0.15–0.60%, Carbon (C) ≤0.10%, and traces of Manganese, Silicon, and Sulfur. It provides tensile strength up to 600 MPa, yield strength approximately 275 MPa, and elongation of 30%. The alloy is of a density of 7.94 g/cm³ and a melting point of around 1357–1385°C, making it long-lasting under high-temperature applications.
| Standards : | ASTM B408, ASME SB408 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 800 Bar in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 800 Bars are extensively employed in situations where resistance to corrosion and high temperature is paramount. They find application in heat exchangers, reactors, and process piping in the chemical and petrochemical sectors. Power plants use them in reheaters, superheaters, and steam lines because of their thermal resistance. In the aerospace industry, Inconel 800 bars find application in jet engine components and exhaust systems. They are also well-suited for nuclear power generation applications, industrial furnaces, and thermal processing equipment, where they resist oxidation, carburization, and prolonged structural degradation at high temperatures.
