Mumbai, India-based Jyoti Steels is a prominent producer and supplier of Inconel 690 Bars with superior resistance to high-temperature corrosion and oxidation. With its reputation for high quality, accuracy, and dependable supply, Jyoti Steels supplies products to industries including nuclear power, chemical processing, and heat treatment. The Inconel 690 bars offered by the company are produced according to tight international standards and are best suited for use in highly corrosive and high-temperature conditions. Jyoti Steels promises to provide strong and long-lasting solutions as per stringent industrial demands.
Inconel 690 Bars consist of a high-nickel alloy possessing high metallurgical stability and corrosion resistance. The chemical composition is as follows: Nickel (Ni) 58–63%, Chromium (Cr) 27–31%, Iron (Fe) 7–11%, trace amounts of Silicon (Si) ≤0.5%, Manganese (Mn) ≤0.5%, Carbon (C) ≤0.05%, and Aluminum and Titanium ≤0.5% each. Mechanically, the bars possess tensile strength of ~414 MPa, yield strength of ~205 MPa, and elongation of 30%. They have a density of 8.19 g/cm³ and a melting range of 1343–1377°C, and they are best used in high-temperature structural as well as corrosive service applications.
| Standards : | ASTM B166, ASME SB166 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | Ni | Cr | Fe | C | Mn | S | Mo | Si | Co |
| Inconel 690 | 48.85 – 62 | 20 – 24.0 | Balance | ≤ 0.15 | ≤ 1 | – | 8 – 10 | ≤ 1 | 10-15 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.28 g/cm3 | 1430°C | 1267 MPa | 868 MPa | 25 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 690 Bar in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 690 Bars are widely utilized in applications involving severe heat and corrosive aggression. In the nuclear sector, they are applied in steam generator tubes and reactor parts because of their stress corrosion cracking resistance. In the chemical processing industry, these bars are applied in heat exchangers, piping systems, and reactors that are exposed to harsh oxidizers. Power plants utilize them in superheaters and condensers, and thermal processing industries utilize them in furnace components and fixtures. Their high mechanical strength and ability to withstand continued heat exposure for long periods make them perfect for marine uses as well as for environmental engineering applications.
