Jyoti Steels is a well-known Incoloy 800, 800H, and 800HT Pipe Fitting manufacturer and supplier, headquartered in Mumbai, India. With years of experience and a dedication to providing top-quality alloy solutions, Jyoti Steels has gained a strong foothold in domestic and global markets. The company provides a wide range of pipe fittings that are known for their high strength, corrosion resistance, and dependability in high-temperature applications. Committed to excellence, Jyoti Steels serves diverse industrial segments with precision-engineered products that conform to high international standards.
Incoloy 800/800H/800HT Pipe Fittings are nickel-iron-chromium alloys consisting mainly of Ni (30-35%), Cr (19-23%), and Fe (39.5% min), with trace elements such as Al (0.15-0.60%) and Ti (0.15-0.60%). These fittings possess superior mechanical properties, such as tensile strength of 520 MPa, yield strength of 205 MPa, and elongation of 30%. Their physical characteristics are a density of 7.94 g/cm³, melting range of 1357–1385°C, and better thermal stability. They are best suited for high-temperature applications where oxidation and carburization resistance is essential.
Specifications : ASTM B366 / ASME SB366
Size : Seamless Inconel / Incoloy Butt Weld Fittings: 1/2″ – 10″
Welded Inconel / Incoloy Butt Weld Fittings: 1/2″ – 48″
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Thickness : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Types : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Pipe Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Pipe Fittings | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Pipe Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Pipe Fittings are extensively used in high-temperature strength and corrosion-resistant industries. Typical applications include heat exchangers, furnace parts, petrochemical processing equipment, power generation facilities, and nuclear reactors. They are well-suited for application in oxidizing and reducing atmospheres because they are resistant to oxidation, sulfidation, and carburization. The alloys also work effectively in high-pressure steam and acid atmospheres and are applicable in chemical processing, hydrocarbon cracking, and superheaters. Their resistance to structural damage under harsh conditions provides consistent performance and long service life in mission-critical systems.
