Jyoti Steels is a renowned manufacturer and supplier of Incoloy Pipe located in Mumbai, India. Renowned for providing nickel alloy piping solutions of superior quality, the company serves industries including chemical processing, power generation, oil & gas, and marine engineering. Prioritizing strength and corrosion resistance, Jyoti Steels offers Incoloy pipes designed to perform in extreme temperatures and aggressive chemical environments. Supported by years of experience in the industry and compliance with international standards, Jyoti Steels is a trusted supplier of strong and durable Incoloy pipe solutions.
Incoloy Pipe, especially in grade 800, normally consists of 30–35% Nickel, 19–23% Chromium, and not less than 39.5% Iron. It further comprises Titanium (0.15–0.60%), Aluminum (0.15–0.60%), Carbon (up to 0.10%), and Manganese (up to 1%). These pipes have a tensile strength of approximately 520 MPa, yield strength of 205 MPa, and elongation of approximately 30%. The density is 7.94 g/cm³, while the melting point is between 1357°C and 1385°C. Incoloy pipes are highly resistant to carburization, oxidation, and stress-related corrosion in both high-temperature and corrosive service conditions, sustaining mechanical stability and long service life.
Specifications : ASTM B423, B705, B704 / ASME SB423, SB705, SB704
Standard : ASTM, ASME and API
Size : 15″NB – 150″NB
Outer Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Length : Single Random, Double Random & Cut Length
Schedule : SCH 10, SCH20, SCH30, SCH50, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Types : Seamless / ERW / Welded / EFW / Fabricated / CDW
| Grade | C | Al | Ti | S | Cu | Fe | Ni |
| Incoloy Pipe | 0.05 max | 0.2 max | 0.6 – 1.2 | 0.03 max | 1.5 – 3.0 | 22.0 min | 38.0 – 46.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Pipe | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Pipes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy Pipes find wide application in those uses where high temperature strength and corrosion resistance are required. They are utilized in piping aggressive chemicals like sulfuric, nitric, and phosphoric acids in the chemical and petrochemical processes. Power generation plants utilize Incoloy pipes in heat exchangers, steam pipes, and superheaters. They find application in the marine industry for piping systems in saltwater and high-humidity environments. Aerospace and nuclear industries take advantage of their operation in harsh environments. They are also used in furnace elements and refinery equipment where structural integrity and oxidation resistance are essential under prolonged thermal cycling.
