Jyoti Steels, Mumbai, India, is a reliable manufacturer and supplier of high–quality Incoloy Forged Fittings catering to various industrial sectors. Renowned for their strength, corrosion resistance, and precision, Jyoti Steels offers Incoloy forged fittings across various grades and specifications following international standards. These fittings are best suited for high-performance applications in corrosive environments, such as petrochemical, power generation, and marine sectors, where the resistance to oxidizing and reducing agents and toughness are essential.
Incoloy Forged Fittings consist mostly of Nickel (30–46%), Iron (39.5% min), and Chromium (19–23%), with small additions of Molybdenum (2.5–3.5%), Copper (1.5–3%), Titanium (0.6–1.2%), and small traces of Carbon (0.05% max). These fittings exhibit a tensile strength of 585 MPa, yield strength of 240 MPa, and elongation of 30%, ensuring that they are mechanically strong. They possess a density of 8.14 g/cm³ and a melting point range from 1370°C to 1400°C, which aids in providing great performance in corrosive and high-temperature applications.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Incoloy Forged Fittings are widely utilized in chemical processing, nuclear fuel reprocessing, pollution control, offshore oil and gas production, and marine industries. Their resistance to reducing and oxidizing acids, chloride corrosion, pitting, and crevice attack makes them ideal for use in heat exchangers, pressure vessels, condensers, and piping systems. The fittings are also well suited for power plants, acid leach systems, and hydrometallurgy, where corrosion and durability are a necessity. Their high stability and strength in aggressive environments guarantee long service life and worry-free operation in critical processes.
