Jyoti Steels, Mumbai, India, is a leading producer and supplier of high-performance Forged Fittings Incoloy 825, which serve the demands of industries working in extremely corrosive and demanding conditions. It is famous for its focus on quality and precise engineering and supplies forged fittings of international quality and high performance and durability with great resistance. These fittings are extensively utilized in industries like chemical processing, oil and gas, marine, and pollution control because of their strength, corrosion resistance, and ability to operate under high pressure and temperature.
Incoloy 825 Forged Fittings are produced with a chemical composition of Nickel (38–46%), Iron (min 22%), Chromium (19.5–23.5%), Molybdenum (2.5–3.5%), Copper (1.5–3%), and Titanium (0.6–1.2%), along with Carbon (max 0.05%), Manganese (max 1%), and Silicon (max 0.5%). These fittings have good mechanical properties such as tensile strength of 690 MPa, yield strength of 275 MPa, and elongation of 30%. Their physical properties are density of 8.14 g/cm³ and a melting point of 1370–1400°C, providing better resistance to oxidation, pitting, crevice corrosion, and acidic media.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Incoloy 825 Forged Fittings have wide application in chemical plants, marine hardware, pollution control equipment, oil and gas refineries, power stations, and nuclear fuel reprocessing. Their superior resistance to sulfuric, phosphoric, and nitric acids and also their suitability to work in oxidizing as well as reducing environments renders them appropriate applications in heat exchangers, pressure vessels, piping systems, condensers, and reactors. These fittings provide secure, leak-proof connections in both high-temperature and high-pressure applications, rendering them a preferred option for essential fluid and gas handling systems used in a vast array of industries.
