Mumbai, India-headquartered Jyoti Steels is a prominent manufacturer and exporter of Incoloy Stud Bolts for various industrial applications. With a quality-centric approach, precision, and customer satisfaction at the forefront, Jyoti Steels provides high-quality fastening solutions that adhere to high industry standards. Their Incoloy Stud Bolts are engineered to perform exceptionally well in harsh environments, such as high-temperature and corrosive conditions, and are thus a perfect fit for industries like petrochemicals, power generation, and shipping industries. Jyoti Steels has built a reputable name for providing tough and consistent products to customers throughout India and overseas.
Incoloy Stud Bolts, especially Incoloy 800 Stud Bolts, are made up of Nickel (30.0–35.0%), Chromium (19.0–23.0%), Iron (balance, minimum 39.5%), Copper (up to 0.75%), Titanium (0.15–0.60%), Aluminum (0.15–0.60%), Carbon (max 0.10%), Manganese (max 1.5%), Sulfur (max 0.015%), and Silicon (max 1.0%). These bolts have tensile strength of approximately 520 MPa, yield strength of 205 MPa, and elongation of approximately 30–35%. Their density is around 7.94 g/cm³, and they have a melting point of 1350–1400°C. These values provide outstanding performance in high-temperature, high-stress, and corrosive environments.
| Specification | ASTM F468, B425 / ASME SF468, SB425 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy Stud Bolts are used extensively in industries requiring high strength and corrosion resistance. In the petrochemical industry, they are critical for holding parts in heat exchangers, pressure vessels, and reactors. They are employed by power plants in boilers, condensers, and superheaters because they are stable at high temperatures. In the maritime industry, their seawater corrosion resistance makes them suitable for use in offshore platforms and shipbuilding. They are also used in nuclear power plants, pollution abatement systems, and chemical processing plants where they provide long-term reliability and strength in harsh operating conditions.
