Jyoti Steels is a reliable manufacturer and supplier of Incoloy 800, 800H, and 800HT Forged Fittings, having its headquarters in Mumbai, India. With its emphasis on quality and customer satisfaction, the company provides high-performance alloy fittings as per international standards. Due to their strength and resistance to harsh environments, Jyoti Steels‘ forged fittings are extensively used in a number of industries. The company utilizes superior manufacturing processes and stringent quality checks to supply stable and accurate forged fittings appropriate for high-temperature and corrosive applications across the globe.
Incoloy 800/800H/800HT Forged Fittings are nickel-iron-chromium alloys with the chemical composition of Nickel 30–35%, Chromium 19–23%, Iron balance, Carbon up to 0.10% (800H), Aluminum 0.15–0.60%, and Titanium 0.15–0.60%. These alloys possess superior mechanical properties, including tensile strength of 520 MPa, yield strength of 205 MPa, and elongation of 30%. Physical properties are a density of 7.94 g/cm³, melting point range of 1357–1385°C, and superior resistance to thermal creep and corrosion, which makes them suitable for harsh environments.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800H Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Forged Fittings find wide application in chemical processing, power generation, oil and gas, and nuclear energy industries. Their strength retention and resistance to oxidation and carburization at high temperatures make them ideal for heat exchangers, furnace components, superheater tubing, and reformer outlets. They are also ideal for high-pressure steam lines and acid environments, providing long service life and safe operation. Their strong structure and thermal stability render them a choice for systems that are subjected to both high temperatures and harsh chemical exposure.
