Mumbai-based Jyoti Steels is a prominent producer and exporter of high–grade Incoloy 825 Flanges, serving industries demanding superior corrosion resistance and tensile strength in piping fittings. Committed to quality and accuracy, Jyoti Steels provides Incoloy 825 flanges of international standards and resistance to harsh chemical and marine atmospheres. Such flanges are specifically designed to deliver long life service, reliability, and strength. These flanges are hence apt for highly important applications in areas like oil & gas, power generation, chemical processing, marine, etc.
Specifications : ASTM B 564 / ASME SB 564
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Standards : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges etc.
Size : 1/2″ to 36″
Pressure Rating : Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
| C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti | |
| Incoloy | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Incoloy Flanges | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Flanges in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Flanges find extensive application in chemical plants, marine environments, offshore oil and gas platforms, nuclear fuel processing, and pollution control equipment. Due to their outstanding resistance to phosphoric and sulfuric acids and chloride-induced stress corrosion cracking, they are suited for acid storage tanks, reactors, heat exchangers, pipelines, and scrubbers. These flanges are constructed to provide safe and leak-free connections in systems subjected to high temperature, pressure, and corrosive materials. Their strength and operability in harsh industrial environments make them a choice for extended and reliable service in challenging environments.
