Mumbai, India-based Jyoti Steels is a prominent manufacturer and supplier of high-performance Maraging Steel Bars, designed to provide superior strength, toughness, and dimensional stability. Focused on precision and international quality standards, Jyoti Steels caters to critical sectors such as aerospace, defense, tooling, and automotive. Maraging steel bars from Jyoti Steels are characterized by low carbon levels, high weldability, and resistance to crack growth and thus are best suited to high-stress applications requiring reliability and long life under severe mechanical loading.
Maraging Steel Bars are generally made up of Nickel (Ni) 17–19%), Cobalt (Co) 8–12%), Molybdenum (Mo) 3–5%), and minor amounts of Titanium (Ti) 0.1–0.5%), Aluminum (Al) 0.05–0.15%), and Carbon (C ≤ 0.03%). Such bars have extremely high tensile strength (upto 2000 MPa) and yield strength more than 1500 MPa, with elongation ranging from 6–15%, based on heat treatment. The density is around 8.0 g/cm³, and they provide superior dimensional stability, low thermal expansion, and high hardness following aging. They can be accurately customized through heat treatment, suitable for high-precision, fatigue-resistant parts.
| Standard : | AMS, AMS, API |
| Specification : | ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101 |
| Size : | 20mm x 1200 x 500 |
| Specialize Sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000) |
| Grade | C | Mn | Si | Co | Fe | Ni | Mo | Ti | Al |
| Maraging C250 | .03max max | .10max max | .10max max | 7.50 max | Bal | 18.50 min | 4.80 max | .40 max | .10 max |
| Maraging C300 | .03max max | .10max max | .10max max | 9.0 max | Bal | 18.50 min | 4.80 max | .60 max | .10 max |
| Maraging C350 | .03max max | .10max max | .10max max | 12.0 max | Bal | 18.50 min | 4.80 max | 1.40 max | .10 max |
| Grade | Density | Average Coefficient of Thermal Expansion | Modulus of Elasticity |
| Maraging 250 | .289 lbs./cu.in | 5.6 x 10-6 in./ in./ ºF | 5.6 x 10-6 in./ in./ ºF |
| Maraging 300 | .289 lbs./cu.in | .289 lbs./cu.in | 292 lbs./cu.in |
| Maraging 350 | .289 lbs./cu.in | 6.3 x 10-6 in./ in./ ºF | 29.0x 10-6 psi |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Maraging Steel Bar in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Maraging Steel Bars find application in high-performance applications that demand higher strength, toughness, and resistance to fatigue. In aerospace, maraging steel bars are employed for aircraft landing gear, rocket motor casings, and for structural components. In defense applications, they are employed in missile systems, tank parts, and ballistic applications. The tooling industry employs maraging steel bars for high-strength dies, moulds, and extrusion tools because of their superior machinability and wear resistance. They are also employed in automotive and motorsport industries for shafts and drivetrain components. Nuclear and aeronautical industries also depend on them for mission-critical components that require maximum strength and reliability.
