Jyoti Steels is a renowned manufacturer and supplier of Niobium Bar situated in Mumbai, India, providing high-performance and high-purity materials for precision industrial uses. Jyoti Steels, with its deep emphasis on precision and quality, provides niobium bars that conform to international standards for aerospace, electronics, nuclear, and medical uses. Supported by sophisticated infrastructure and strict quality checks, the company provides consistent product performance, assured supply, and customization to suit specific client needs. Jyoti Steels is known for its focus on innovation, excellence, and timely delivery in both domestic and international markets.
Niobium Bars usually comprise Niobium (≥99.9%) with impurities like Tantalum (≤0.1%), Iron (≤0.05%), Titanium (≤0.01%), and Tungsten (≤0.05%). These bars provide superior ductility and corrosion resistance. Niobium mechanically possesses a tensile strength of approximately 275 MPa, yield strength of 170 MPa, and elongation of approximately 40%. Niobium has a density of 8.57 g/cm³ and a high melting point of around 2477°C, with excellent thermal conductivity and superconducting behavior. Due to its high purity and resistance to aggressive chemicals, it can be used in high-performance and high-temperature applications.
| Standards : | ASTM B392, ASME SB392 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Element | Niobium R04200 | Niobium R04210 | Nb-1%Zirconium R04251 | Nb-1%Zirconium R04261 |
| C | 0.01 | 0.01 | 0.01 | 0.01 |
| N | 0.01 | 0.01 | 0.01 | 0.01 |
| O | 0.015 | 0.025 | 0.015 | 0.025 |
| H | 0.0015 | 0.0015 | 0.0015 | 0.0015 |
| Zr | 0.02 | 0.02 | 0.8 to 1.2 | 0.8 to 1.2 |
| Ta | 0.1 | 0.3 | 0.1 | 0.5 |
| Fe | 0.005 | 0.01 | 0.005 | 0.01 |
| S | 0.005 | 0.005 | 0.005 | 0.005 |
| W | 0.03 | 0.05 | 0.03 | 0.05 |
| Ni | 0.005 | 0.005 | 0.005 | 0.005 |
| Mo | 0.010 | 0.020 | 0.010 | 0.050 |
| Hf | 0.02 | 0.02 | 0.02 | 0.02 |
| Ti | 0.02 | 0.03 | 0.02 | 0.03 |
| B | 2ppm | – | 2ppm | – |
| Al | 0.002 | 0.005 | 0.002 | 0.005 |
| Be | 0.005 | – | 0.005 | – |
| Cr | 0.002 | – | 0.002 | – |
| C | 0.002 | – | 0.002 |
| Grade | Ultimate Tensile Strength, Min, Psi(MPa) | Yield Strength, Psi(MPa) | Elongation min %,mm |
| Types 1 and 2 | 18 000 (125) | 10 500 (73) | 20 |
| Types 3 and 4 | 28 000 (195) | 18 000 (125) | 15 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Niobium Bar in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Niobium Bars have extensive applications in industries requiring strength, corrosion resistance, and high-temperature stability. In aerospace, they find application in jet engines and rocket parts because of their resistance to heat. Niobium is utilized in the electronics industry in superconductors, capacitors, and semiconductor production. In the nuclear industry, niobium bars are utilized in reactor parts because of their low neutron absorption and radiation stability. They are also crucial in the medical sector for implants and surgical instruments due to their biocompatibility. They are also employed in chemical processing equipment dealing with highly corrosive chemicals.
