Mumbai, India-based Jyoti Steels is a reputable manufacturer and supplier of superior-quality Zirconium Bars for industrial and specialized purposes. Famous for their remarkable resistance to corrosion and high-temperature stability, Zirconium Bars are suitable for application in hostile environments. Jyoti Steels guarantees quality of the highest order by maintaining international standards and adopting the latest production technologies. With emphasis on precision and reliability, the company manufactures Zirconium Bars for application in industries including nuclear energy, chemical processing, aerospace, and marine, meeting domestic and global clients with stability and professionalism.
Zirconium Bars usually consist of Zr 95–98%, Hf <4.5%, Fe <0.2%, Cr <0.1%, O <0.16%, N <0.025%, C <0.05%. This composition provides outstanding corrosion resistance, particularly against acids and alkalis. Tensile strength is 330–680 MPa, yield strength is 230–600 MPa, and elongation up to 25–30%. Density is approximately 6.52 g/cm³, and melting point is about 1855°C. Zirconium is paramagnetic, thermal conductivity ~22.7 W/m·K, and chemically very stable at high temperature, so best for harsh, critical operating conditions, particularly for nuclear and chemical applications.
| Standards : | ASTM B493 |
| Size : | 5.0mm diameter x L |
| Specification : | ASTM B550/550M-07 |
| Length : | 2m, 2.44m, 3m, or as required |
| Surface : | Turning, Grinding |
| Grade | Zr+Hf | Hf | Fe+Cr | Sn | H | N | C | O | Nb |
| R60702 | 99.2% | <4.5% | <0.20% | – | <0.005% | <0.015% | <0.030% | <0.15% | – |
| R60704 | 97.5% | <4.5% | 0.2-0.4% | 1.0-2.0% | <0.005% | <0.015% | <0.030% | <0.16% | – |
| R60705 | 95.5% | <4.5% | <0.2% | – | <0.005% | <0.015% | <0.050% | <0.16% | 2.0-3.0% |
| Molecular Weight | 91.22 |
|---|---|
| Appearance | White |
| Melting Point | 1852 °C |
| Boiling Point | 3580 °C |
| Density | 6506 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 40.0 microhm-cm @ 20 oC °C |
| Electronegativity | 1.4 Paulings |
| Heat of Fusion | 5.50 Cal/gm mole |
| Heat of Vaporization | 120 K-Cal/gm atom at 4377 °C |
| Poisson’s Ratio | 0.34 |
| Specific Heat | 0.0671 Cal/g/K @ 25 oC °C |
| Tensile Strength | 230 MPa |
| Thermal Conductivity | 0.227 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 5.7 µm·m-1·K-1 |
| Vickers Hardness | 903 MPa |
| Young’s Modulus | 88 GPa |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Zirconium Bar in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Zirconium Bars find wide application in the nuclear field for cladding fuel rods and structural parts because of their low absorption of neutrons. They are best suited in the chemical processing industry for the fabrication of reactor vessels, heat exchangers, and pumps used for highly corrosive materials such as hydrochloric and sulfuric acids. They are utilized in the aerospace industry for high-temperature and oxidation-resistance applications. Marine applications also find them suitable under saline conditions. Zirconium Bars are utilized in medical equipment, electronic components, and lab equipment that need inert and resilient material. Their ability to work consistently in extreme environments makes them useful in various high-tech applications.
