Jyoti Steels is a well-known manufacturer and supplier of A286 Sheets and Plates in Mumbai, India. We offer high-performance, high-quality alloy materials designed to meet the requirements of applications demanding outstanding strength and oxidation resistance at high temperatures. Our A286 Sheets and Plates have extensive applications in aerospace, automotive, chemical processing, and power generation sectors. Produced as per international standards, our products provide better workability and durability. Jyoti Steels is dedicated to providing precision-engineered alloy solutions that fulfill challenging specifications and cater to domestic and international customers.
A286 Sheets and Plates are iron-based superalloys with a content of about 50.5–52% Iron (Fe), 24–27% Nickel (Ni), 13.5–16% Chromium (Cr), 1.0–2.5% Titanium (Ti), 0.75–1.5% Molybdenum (Mo), and trace amounts of Vanadium, Manganese, and Carbon. A286 plates provide tensile strength of about 960 MPa, yield strength of 550–690 MPa, and elongation of 25–30%. A286 has a density of 7.93 g/cm³ and superior oxidation resistance up to 815°C. It has good creep resistance and dimensional stability at elevated temperatures, and it is well suited for both cryogenic and high-temperature service in harsh environments.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of A286 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
A286 Sheets and Plates find applications in high-stress and high-temperature conditions in various industries. In the aerospace industry, they are utilized in turbine engines, afterburners, and fasteners. The automotive sector utilizes A286 in exhaust systems and turbochargers. For heat exchangers, reactors, and superheater tubes in power generation and chemical processing, these plates are ideal. With their superior oxidation and corrosion resistance, they find applications in marine parts and gas turbines. Because of their high strength and favorable formability, they are also the preferred option for structural parts subjected to thermal cycling and high-pressure conditions.
