Jyoti Steels is a well-known Mumbai-based manufacturer and supplier of Manganese Bronze Sheets and Plates, supplying high-performance alloys to diverse industries. Our Manganese Bronze products are highly in demand due to their excellent strength, corrosion resistance, and long life, used in applications requiring superior mechanical properties and extended service life. We at Jyoti Steels maintain accurate manufacturing standards, supplying to marine, aerospace, defense, and engineering industries. Our dedication to quality, timely delivery, and tailored solutions has established us as a reliable name in the Indian and international metal markets.
Manganese Bronze Sheets and Plates generally consist of Copper (55–65%), Zinc (20–25%), Manganese (2.5–5%), Aluminum (0.5–1.5%), and Iron (2.5–4%). These components impart superior mechanical properties, such as tensile strength of 550–700 MPa, yield strength of 300–450 MPa, and elongation of 20–30%. The alloy also provides good hardness (about 100–150 HB) and superior corrosion and wear resistance. Physically, Manganese Bronze possesses a density of about 8.2 g/cm³ and shows dimensional stability in marine and industrial conditions, thus being suitable for high–stress and corrosive condition-exposed components.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Manganese Bronze Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Manganese Bronze Sheets and Plates are extensively used in applications where strength, corrosion resistance, and machinability are paramount. Some common applications are in marine hardware like propeller shafts, pump components, and valves, because of their saltwater corrosion resistance. They find applications in bushings, bearings, and gears in the aerospace and auto industries. Applications in industry involve heavy-duty fasteners, hydraulic equipment components, and construction equipment. Their anti-sparking property also lends them to places where there may be flammable gases or vapors, providing safety and reliability in harsh operating conditions.
