Home > Alloy C263 Sheets and Plates
Jyoti Steels in Mumbai, India, is one of the premier manufacturers and suppliers of high-performance Alloy C263 Plates and Sheets. Jyoti Steels has a reputation for providing corrosion-resistant and heat-resistant solutions and, as such, offers Alloy C263 products that fulfill the demanding requirements of aerospace, power generation, and high-temperature industrial applications. Having a devotion to quality, accuracy, and global standards, the company assures every sheet and plate to provide maximum strength and endurance. Supported by sophisticated manufacturing facilities and rigorous quality checks, Jyoti Steels is a reliable name for Alloy C263 products in India and international markets.
Alloy C263 Sheets and Plates consist of about 50–55% Nickel, 19–21% Chromium, 19–21% Cobalt, 5.6–6.1% Molybdenum, 0.6% Titanium, 2.1% Iron, and trace amounts of Aluminum (~0.5%) and Carbon (<0.06%). The composition ensures high-temperature strength and resistance to oxidation. They have tensile strength of 850–1100 MPa and yield strength of 500–700 MPa, with elongation of about 20–25%. In physical terms, Alloy C263 weighs 8.36 g/cm³ and melts at around 1355°C. It also remains stable and strong at temperatures of up to 900°C, which suits it for environments with high stress and heat levels.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy C263 Sheets and Plates find their major applications in those processes where superior strength and oxidation resistance at high temperatures are needed. In aerospace, they find their applications in turbine engine parts, combustion liners, and exhaust systems. Power generation plants use them in gas turbines, heat exchangers, and high-temperature ducts. They also find their applications in petrochemical processing as well as industrial furnaces because of their thermal fatigue and scaling resistance. Their exceptional weldability and formability render them ideal for cyclic thermal stress-exposed components, providing long term durability in harsh service conditions.
