Jyoti Steels is one of the reliable manufacturers and suppliers of Zirconium Sheet and Plate in Mumbai, India. We are leading in producing high-purity zirconium products that conform to rigorous international specifications, thus suitable for application in highly corrosive as well as high-temperature conditions. Our Zirconium Sheets and Plates are renowned for their superior chemical attack resistance, mechanical strength, and extended service life. Supplying industries like nuclear, chemical, and aerospace, Jyoti Steels provides precision engineering, consistent performance, and timely delivery for all your critical material needs.
Zirconium Plate and Sheet normally have Zirconium (Zr) minimum 99.2%, traces of Hafnium (Hf) up to 2.5%, with negligible quantities of Fe, Cr, N, H, C, and O. The mechanical properties of zirconium are a tensile strength of 380 MPa and yield strength of approximately 230 MPa. It is very ductile and corrosion-resistant. Physically, it possesses a density of 6.52 g/cm³, a melting point of 1855°C, and a thermal conductivity of 22.6 W/m·K. These attributes render zirconium sheets and plates suitable for use in extreme chemical and nuclear environments.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Products | Chemical Composition(wt%≤) | ||||||||
| Cd | Co | Cu | Hf | Mg | Mn | Mo | Si | Ti | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60802 (Zr-2) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60804 (Zr-4) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60901 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60904 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.005 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| Products | Chemical Composition (wt%≤) | ||||||||
| U | V | W | C | N | H | O | |||
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60802 (Zr-2) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60804 (Zr-4) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60901 (Zr-2.5Nb) | 0.0035 | – | 0.010 | 0.027 | 0.0080 | 0.0025 | 0.09-0.15 | ||
| R60904 (Zr-2.5Nb) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.01-0.14 | ||
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Zirconium Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Zirconium Sheet and Plate find extensive usage in industries demanding exceptional corrosion resistance and heat stability. In the nuclear industry, they find application in fuel rod and reactor component cladding because of their low neutron absorption. Chemical processing industry applies zirconium to reactors, heat exchangers, and piping systems for strong acids. Aerospace and defense industries are helped by zirconium’s strength-to-weight ratio and resistance to aggressive surroundings. It is also utilized in medical implants, drug equipment, and electronics. Such plates are essential wherever there is a need for high performance, long life, and chemical degradation resistance.
