Jyoti Steels is a well-known producer and distributor of MP35N Sheets and Plates from Mumbai, India. Reputable for supplying high-strength and corrosion-resistance alloys, Jyoti Steels offers quality MP35N materials to meet global standards. Jyoti Steels services various industries like aerospace, medical, and chemical processing with materials that possess superior mechanical properties and dependability. Through cutting-edge manufacturing and precision focus, Jyoti Steels ensures that its MP35N sheets and plates exhibit consistent performance in the most harsh environments.
MP35N is a cobalt-nickel-based alloy that has about Cobalt (35%), Nickel (35%), Chromium (20%), and Molybdenum (10%). It also consists of trace levels of Iron (<1%) and Carbon (<0.025%). This alloy exhibits good corrosion resistance, high yield strength (up to 1793 MPa), and tensile strength (up to 2068 MPa), in addition to possessing good ductility (elongation ~30%). MP35N possesses a melting range of 1399–1454°C and a density of 8.43 g/cm³. Its non-magnetic properties and high fatigue resistance make it well-suited for high-stress, critical applications.
| Standard Specification : | ASTM F562 / ASME SF562 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Chemical Analysis | |
| Cr | 20 nom |
| Ni | 35 nom |
| Mo | 10 nom |
| Co | 35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
MP35N Sheets and Plates find extensive applications in those industries where there is a need for top-level strength and corrosion resistance. In the medical sector, they are best suited to surgical tools and orthopedic devices because they are biocompatible. In aerospace applications, MP35N finds application in fasteners, springs, and structural components that are subject to aggressive conditions. The alloy is also used in chemical processing equipment, marine hardware, and oil & gas systems where corrosive environment exposure is routine. Its superior mechanical properties also render it fit for high-performance electronics and defense systems.
