Home > Niobium Sheet and Plates
Jyoti Steels, Mumbai, India, is a reliable manufacturer and supplier of high-performance Niobium Sheets and Plates, renowned for their superior performance across industries. Jyoti Steels, driven by innovation and exceptional craftsmanship, offers Niobium products that are international standard in terms of durability, strength, and corrosion resistance. Their knowledge and high-tech production processes guarantee Niobium Sheets and Plates with high accuracy to serve industries like aerospace, electronics, and chemical processing, where dependability and performance are most important in stringent applications.
Niobium Sheets and Plates are made mostly of 99.95% pure niobium with minor impurities such as iron (≤0.05%) and oxygen (≤0.05%). The material shows excellent mechanical behavior, with tensile strength varying from 200 MPa to 400 MPa, based on the alloy grade. Its density is 8.57 g/cm³ and is extremely corrosion– and oxidation-resistant. Niobium is stable in its strength at high temperatures and is not reactive to most acids. Due to its high thermal and electrical conductivity, it is perfectly suited for high-performance use in harsh environments.
| Grade : | Nb1,NbZr,R04200 |
| Standard : | ASTM B393-05 |
| Purity : | 99.95% |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size: | Thick 0.1mm min.W680mm max. L3000mm max |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Applications : | Semiconductor materials, vacuum coating, sintering trays and boats, special chemical applications. |
| STANDARD | UNS | Material No |
| Niobium | R04200 | – |
| Element | Type 1 (Reactor Grade Unalloyed Nb) R04200 | Type 2 (Commercial Grade Unalloyed Nb) R04210 | Type 3 (Reactor Grade Nb-1%Nb) R04251 | Type 4 (Commercial Grade Nb-1%Nb) R04261 |
| Max Weight % (Except Where Otherwise Specified) | ||||
| C | 0.01 | 0.01 | 0.01 | 0.01 |
| N | 0.01 | 0.01 | 0.01 | 0.01 |
| O | 0.015 | 0.025 | 0.015 | 0.025 |
| H | 0.0015 | 0.0015 | 0.0015 | 0.0015 |
| Zr | 0.02 | 0.02 | 0.8 – 1.2 | 0.8 – 1.2 |
| Ta | 0.1 | 0.3 | 0.1 | 0.5 |
| Fe | 0.005 | 0.01 | 0.005 | 0.01 |
| Si | 0.005 | 0.005 | 0.005 | 0.005 |
| W | 0.03 | 0.05 | 0.03 | 0.05 |
| Ni | 0.005 | 0.005 | 0.005 | 0.005 |
| Mo | 0.010 | 0.020 | 0.010 | 0.050 |
| Hf | 0.02 | 0.02 | 0.02 | 0.02 |
| Ti | 0.02 | 0.03 | 0.02 | 0.03 |
| Grade Chart | Tensile Ultimate Strength, Minimum,psi(MPa) | Yield Strength Minimum, psi (MPa) | Elongation in 1-inch | |
| 0.010 inch or Greater | Less Than 0.010 inch | |||
| Types 1 and 2 | 18 000 (125) | 10 500 (73) | 20 | 15 |
| Types 3 and 4 | 28 000 (195) | 18 000 (125) | 20 | 15 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Niobium Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Niobium Sheets and Plates are extensively applied in the aerospace industry to produce rocket nozzles, gas turbines, and heat shields because of their melting point and thermal stability. Niobium is also applied in electronics for use in capacitors and superconducting materials because it has good conductivity and corrosion resistance. Niobium is also utilized in medicine for implants and prosthetics because of its biocompatibility. Moreover, Niobium Sheets and Plates are utilized in chemical processing industries for corrosion-resistant parts, and in jewelry and industrial uses where strength, resistance, and lightness are needed.
