Home > Beryllium Copper Sheets and Plates
Jyoti Steels, Mumbai, India, is a reliable manufacturer and supplier of Beryllium Copper Sheets and Plates, providing high-performance materials to various industrial sectors. Due to their strength, conductivity, and accuracy, Beryllium Copper sheets and plates provided by Jyoti Steels are highly valued for their fatigue and stress relaxation resistance. The firm supplies both domestic and international markets with products of world standards in sizes and grades tailored to customers’ specifications, suitable for aerospace, electronics, tooling, and defense use.
Beryllium Copper Sheets and Plates contain 1.8–2.0% Beryllium, 0.2–0.6% Cobalt, and the balance Copper. This alloy provides them with superior strength and conductivity. The material has a tensile strength of 1100–1400 MPa, yield strength of 700–1000 MPa, and elongation of 1–15% based on the temper. It provides thermal conductivity of about 105 W/m·K and electrical conductivity of 20–30% IACS. Its density is 8.25 g/cm³, and melting point is 870–980°C. All these properties make Beryllium Copper a universal alloy for demanding mechanical and electrical uses.
| Standard Specification : | ASTM B194 / ASME B194 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Beryllium Copper Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Beryllium Copper Plates and Sheets are widely utilized in high–strength, conductivity, and fatigue resistance demanding industries. They are suited for the production of electrical connectors, switch elements, springs, and relays in electronics and telecommunication industries. Aerospace and automotive industries employ them in structural parts and engine components owing to their dimensional stability and non-magnetic nature. They are employed in tools used in hazardous conditions where non-sparking materials are needed. Their machinability and corrosion resistance make them ideal not only for precision instruments, molds, but also for military-grade parts.
