Jyoti Steels, Mumbai, India, is a leading manufacturer and supplier of AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod. Renowned for its higher quality welding consumables, Jyoti Steels provides filler materials that are rich in strength, having top-notch corrosion resistance, and are performance-orientated in harsh welding applications. These rods and wires find application in welding Inconel 600, 601, 625, and other equivalent alloys, besides dissimilar metal welding. It is focused highly on quality, accuracy, and customer satisfaction and serves the purposes of power, petrochemical, and aeronautical industries.
AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod is composed of Nickel (Ni 67.0%), Chromium (Cr 20.0–23.0%), Iron (Fe ≤ 3.0%), Manganese (Mn ≤ 2.5%), Niobium + Tantalum (Nb + Ta ≤ 1.0%), and other trace constituents such as Silicon (Si ≤ 0.75%) and Carbon (C ≤ 0.10%). This makes it exhibit excellent resistance to oxidation and corrosion, especially in high-temperature and aggressive applications. The filler provides a tensile strength of approximately 760 MPa and elongation of 30%. Its density is about 8.4 g/cm³, and melting point is about 1350°C, and it is used in critical high-performance welding processes.
| Classification | AWS A5.14, ERNiCr-3 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCr-3 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Ti | Cr | Tb+Ta | Other |
| 0.10 | 2.5-3.5 | 3.0 | 0.03 | 0.015 | 0.50 | 0.50 | 67.0 min | 0.75 | 18.0-22.0 | 2.0-3.0 | 0.50 |
| Tensile Strength | 85,500 psi |
|---|---|
| Yield Strength | 52,500 psi |
| Elongation | 38% |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod is used extensively in welding nickel-chromium-iron alloys such as Inconel 600 and 601 and in joining different metals like stainless steel to nickel alloys. Their uses are in heat exchangers, furnace parts, chemical process equipment, nuclear power facilities, and marine engineering. They are also used in aerospace and gas turbine applications because they possess strength and stability when they are at high temperatures. With excellent resistance to oxidation, pitting, and crevice corrosion, they are the best for welds that are subjected to harsh thermal and corrosive environments.
