Home > Nickel Alloys > AWS Class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod
Mumbai, India-based Jyoti Steels is a prominent producer and seller of AWS Class ERNi-1 MIG and TIG Filler Welding Wire and Rod, providing top–class nickel alloy filler material conforming to international standards. Earning a reputation for uniform performance, resistance to corrosion, and excellent weldability, the products are best suited for nickel 200/201 joining and dissimilar metal joining. Jyoti Steels offers these filler rods and wires in different diameters, which are suited for both TIG and MIG welding processes in various industrial applications such as marine, chemical processing, and power generation industries.
AWS Class ERNi-1 MIG and TIG Filler Welding Rod and Wire mainly contain Nickel (Ni ≥ 99.6%), with minute proportions of Iron ≤ 0.4%, Carbon ≤ 0.15%, Manganese ≤ 0.35%, Copper ≤ 0.25%, and Sulfur ≤ 0.01%. Its high-purity chemistry provides excellent ductility and corrosion resistance. Some of its mechanical properties are around 415 MPa tensile strength, yield strength of around 105 MPa, and elongation of around 30%. It also has a melting point of about 1446°C and density of about 8.89 g/cm³. It shows good electrical and thermal conductivity, and thus can be used for high-performance welding and critical welding applications.
| Classification | AWS A5.14, ERNiFeCr-1 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiFeCr-1 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Si | Cr | S | P | Ni | Fe | Cu | Al | Mo | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ≤0.05 | ≤1 | ≤0.5 | 19.5-23.5 | ≤0.03 | ≤0.03 | 38-46 | ≥22 | 1.5-3.0 | ≤0.2 | 2.5-3.5 | 0.6-1.2 |
| Tensile Strength MPa(ksi) | Yield Strength MPa(ksi) | Elongation % | |
|---|---|---|---|
| AWS requirement | 550(80) | Not specified | Not specified |
| Typical results as welded | 550(80) | – | 25 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ERNi-1 MIG and TIG Filler Welding Wire and Rod are extensively used to weld pure nickel (Nickel 200/201) as well as to join dissimilar metals like nickel to stainless steel or copper-nickel alloys. Their high resistance to reducing environments, caustic alkalis, and neutral salt solutions makes them perfect for chemical processing, food industry, and marine uses. They find application in nuclear reactors, heat exchangers, and power plants where corrosion resistance and high strength are necessary. These filler materials are employed in applications requiring high integrity welds under harsh service conditions.
