Home > Nickel Alloys > AWS Class ERNiCrMo-4 MIG and TIG Filler Welding Wire and Rod
We, Jyoti Steels, a well-known Mumbai, India-based manufacturer and supplier, provide premium AWS Class ERNiCrMo-4 TIG and MIG Filler Welding Wire and Rod. The filler wires and rods are specifically meant for welding high-strength nickel-chromium-molybdenum alloys, i.e., Inconel 625 and other similar grades, employed in corrosive and high-temperature applications. Renowned for superior weld strength, oxidation resistance, and high corrosion performance, Jyoti Steels’ ERNiCrMo-4 products are to international standards in both industrial fabrication and maintenance purposes. They are highly relied upon in the chemical, offshore, aerospace, and power generation sectors for their accuracy and longevity.
AWS Class ERNiCrMo-4 MIG and TIG Filler Wire and Rod typically contain 57–63% Nickel (Ni), 20–23% Chromium (Cr), 8–10% Molybdenum (Mo), 3.15–4.15% Niobium (Nb), and up to 5% Iron (Fe). The minor constituents are Manganese (≤1.0%), Silicon (≤0.5%), and Carbon (≤0.05%). These fillers exhibit tensile strength of 760–850 MPa, yield strength approximately 550 MPa, and elongation of 25–35%. Density is around 8.44 g/cm³ with a melting point in excess of 1300°C. The excellent corrosion resistance of the alloy, particularly to chlorides and reducing acids, makes it an ideal choice for challenging welds in both cryogenic and high-temperature environments.
| Classification | AWS A5.14, ERNiCrMo-4 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrMo-4 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Co | Cr | Mo | V | W | Other |
| 0.02 | 1.0 | 4.0-7.0 | 0.04 | 0.03 | 0.08 | 0.50 | Rem | 2.5 | 14.5-16.5 | 15.0-17.0 | 0.35 | 3.0-4.5 | 0.5 |
| Tensile (psi) | 100,000 |
|---|---|
| Mpa | 690 |
| Elongation (%) | 30 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCrMo-4 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ERNiCrMo-4 MIG and TIG Filler Welding Wire and Rod are widely applied for welding Inconel 625 and other comparable alloys in severely corrosive or high-temperature service conditions. Typical uses are repair and fabrication of parts in chemical processing facilities, power generation equipment, heat exchangers, offshore petroleum platforms, and marine ships. They are also utilized in the nuclear sector, flue gas desulfurization equipment, and aerospace components. Their resistance to pitting, crevice corrosion, and stress corrosion cracking provides long-term performance in harsh environments. In addition, they are well-suited for cladding and overlay of carbon and low-alloy steel parts.
