Jyoti Steels, a renowned manufacturer and supplier from Mumbai, India, supplies premium-grade AWS Class ERNiCrMo-3 MIG and TIG Filler Welding Wire and Rod. They are specially meant for welding nickel-chromium-molybdenum alloy like Inconel 625 and comparable materials. Popular for their excellent weldability, strength, and durability against hostile environments, these wires and rods find extensive applications in the chemical processing, marine, aerospace, and offshore sectors. Jyoti Steels maintains accurate chemical composition and reliable performance to satisfy stringent requirements of mission-critical industrial applications globally.
AWS Class ERNiCrMo-3 MIG and TIG Filler Wire and Rod has a typical composition of 58–63% Nickel (Ni), 20–23% Chromium (Cr), 8–10% Molybdenum (Mo), 3.15–4.15% Niobium (Nb), and up to 5% Iron (Fe). Other constituents are Manganese (≤1.0%), Silicon (≤0.5%), and Carbon (≤0.05%). It has high tensile strength of 760–850 MPa, yield strength of about 550 MPa, and elongation of 25–35%. The melting point of the alloy is over 1300°C and it has a density of about 8.44 g/cm³. These characteristics make ERNiCrMo-3 ideal for corrosive and high-temperature applications, which will provide optimal durability and weld integrity.
| Classification | AWS A5.14, ERNiCrMo-3 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrMo-3 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Al | Ti | Cr | Nb+Ta | Mo | Other |
| 0.1 | 0.5 | 5.0 | 0.02 | 0.015 | 0.5 | 0.5 | 58 | 0.4 | 0.4 | 20.0-23.0 | 3.15-4.15 | 8.0-10.0 | 0.5 |
| AWS Class: ERNiCrMo-3 | Certification: AWS A5.14/A5.14M:2009 |
| Alloy: ERNiCrMo-3 | ASME SFA A5.4 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCrMo-3 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ERNiCrMo-3 MIG and TIG Filler Welding Wire and Rod find extensive application for welding Inconel 625 and other nickel-based alloys under severe service conditions. Uses involve pressure vessels, heat exchangers, offshore platforms, marine equipment, chemical reactors, and flue gas desulfurizing plants. The process is also employed in welding dissimilar metals like stainless steel to nickel alloys. ERNiCrMo-3 is particularly useful in the presence of chlorides, seawater, and acids because of its high corrosion resistance and mechanical strength. Its flexibility and durability make it a first-rate option for fabrication, cladding, and repair work in industries.
