Mumbai-based Jyoti Steels is a reliable producer and supplier of AWS Class ERNiCu-7 MIG and TIG Filler Welding Wire and Rod. The filler materials are designed to weld nickel-copper alloys like Monel 400 and join dissimilar metals where high corrosion resistance is needed. With their fine weldability, good strength, and resistance to acidic environments as well as seawater, Jyoti Steels’ ERNiCu-7 wires and rods are widely demanded in marine, chemical, and offshore sectors. We supply high-quality filler materials with consistent performance that satisfy international welding standards and stringent service requirements.
AWS Class ERNiCu-7 MIG and TIG Filler Wire and Rod generally consists of 63–70% Nickel (Ni), 29–33% Copper (Cu), ≤2.5% Iron (Fe), ≤2.5% Manganese (Mn), ≤0.75% Titanium (Ti), and ≤0.15% Carbon (C). These percentages provide outstanding resistance to corrosive environments, particularly seawater and reducing acids. The tensile strength is 480–550 MPa, yield strength is about 340 MPa, and elongation is approximately 30–35%. With a density of ~8.9 g/cm³ and a melting point of approximately 1300°C, these fillers provide smooth arc behavior, excellent puddle control, and low porosity, providing strong and high-quality welds in demanding applications.
| Classification | AWS A5.14, ERNiCu-7 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCu-7 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Al | Ti | Other |
| 0.15 | 4.0 | 2.5 | 0.02 | 0.015 | 1.25 | Rem | 62.0-69.0 | 1.25 | 1.5-3.00 | 0.50 |
| AWS Class: ERNiCu-7 | Certification: AWS A5.14/A5.14M:2009 |
| Alloy: ERNiCu-7 | ASME SFA A5.14 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCu-7 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ERNiCu-7 MIG and TIG Filler Welding Wire and Rod are mainly applied to weld nickel-copper alloys such as Monel 400 and Monel K500. They are appropriate for use in marine construction, desalination plants, chemical processing equipment, heat exchangers, and offshore oil platforms. They are also best for welding Monel to carbon or low-alloy steels. Their excellent resistance to seawater corrosion, acidic media, and stress corrosion cracking makes them priceless in hostile environments. ERNiCu-7 filler metals yield tough, ductile welds with excellent mechanical properties and are a trusted option for both fabrication and repair work.
