Jyoti Steels, a Mumbai, India-based firm, is an established maker and supplier of AWS Class ERNiCrMo-13 TIG Filler Welding Rod and AWS Class ERNiCrMo-13 MIG Filler Welding Wire. Specifically designed for harsh welding applications, this high-performance filler metal is suitable for welding advanced nickel-based alloys, especially where higher corrosion resistance and strength are required. Jyoti Steels’ ERNiCrMo-13 products offer superior weldability, heat stability, and resistance to corrosive chemical environments. Supplying the petrochemical, nuclear, and offshore industries, we provide consistent quality and performance to satisfy demanding industrial requirements globally.
AWS Class ERNiCrMo-13 MIG and TIG Filler Wire and Rod has around 50–58% Nickel (Ni), 20–24% Chromium (Cr), 10–12.5% Molybdenum (Mo), 1.5–3% Tungsten (W), 2–4% Cobalt (Co), and up to 5% Iron (Fe). Trace elements are Manganese (≤1%), Silicon (≤0.5%), and Carbon (≤0.03%). The alloy possesses superior mechanical strength with tensile strength of 760–850 MPa, yield strength about 550 MPa, and elongation 25–35%. With a melting point of over 1300°C and a density close to 8.6 g/cm³, ERNiCrMo-13 is perfect for withstanding pitting, stress corrosion cracking, and oxidation in harsh industrial environments.
| Classification | AWS A5.14, ERNiCrMo-13 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrMo-13 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Co | Cr | Mo | V | W | Other |
| 0.02 | 1.0 | 4.0-7.0 | 0.04 | 0.03 | 0.08 | 0.50 | Rem | 2.5 | 14.5-16.5 | 15.0-17.0 | 0.35 | 3.0-4.5 | 0.5 |
| Tensile Strength MPa(ksi) | Yield Strength MPa(ksi) | Elongation % | |
|---|---|---|---|
| AWS requirement | 760(110) | Not specified | Not specified |
| Typical results as welded | 700(102) | 400(58) | 30 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCrMo-13 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
