Mumbai, India-based Jyoti Steels is a leading manufacturer and supplier of AWS Class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod, providing high-quality welding solutions for challenging engineering and industrial applications. With a high emphasis on performance, durability, and accuracy, Jyoti Steels provides products that meet international standards. ERNiFeCr-1 rods and wires are engineered for welding nickel-iron-chromium alloys and offer superior weld integrity, high strength, and oxidation and corrosion resistance. They are best suited for nuclear, chemical processing, aerospace, and power generation applications where reliability is paramount.
AWS Class ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod contain chemical composition of Nickel (Ni ~66%), Iron (Fe ~9%), Chromium (Cr ~22%), Manganese (Mn ≤1%), Silicon (Si ≤0.5%), Carbon (C ≤0.03%), and traces of other elements. They possess good mechanical properties like tensile strength approximately 760 MPa, yield strength approximately 340 MPa, and elongation of 35%. Physically, it possesses a density of approximately 8.4 g/cm³ and a melting range of 1350–1400°C, providing stability in extreme temperatures and resistance to aggressive environments.
| Classification | AWS A5.14, ERNiCrCoMo-1 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrCoMo-1 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Si | Cr | S | P | Ni | Fe | Cu | Al | Mo | Co | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.05-0.15 | ≤1.0 | ≤1.0 | 20-24 | ≤0.015 | ≤0.03 | Rest | ≤3.0 | ≤0.5 | 0.8-1.5 | 8-10 | 10-15 | ≤0.6 |
| Tensile Strength MPa(ksi) | Yield Strength MPa(ksi) | Elongation % | |
|---|---|---|---|
| AWS requirement | 620(90) | Not specified | Not specified |
| Typical results as welded | 770(112) | 610(89) | 28 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCrCoMo-1 MIG and TIG Filler Welding Wire and Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
ERNiFeCr-1 MIG and TIG Filler Welding Wire and Rod are widely used in applications that demand superior thermal and corrosion resistance. They are well suited for welding alloy 800 and similar alloys utilized in high-temperature service in nuclear reactors, chemical processing plants, and heat exchangers. These filler metals are also appropriate for steam generators, boilers, and pressure vessels. Due to their high resistance to carburization and oxidation at high temperatures, they are appropriate for furnace parts and superheater tubing. Their strength and toughness also make them worth using in situations where there is thermal cycling, aggressive chemicals, and mechanical stress.
