Mumbai-based Jyoti Steels is a well-established manufacturer and supplier of high–quality Incoloy 800/800H/800HT Valves, providing dependable and high-performance flow control solutions for challenging industrial applications. Dedicated to precision engineering and global quality standards, Jyoti Steels supplies valves that are perfectly suited to high-temperature and corrosive service applications. These valves are commonly relied upon in petrochemical, power generation, and chemical processing applications, where stability, strength, and resistance to corrosion are crucial for safe and efficient performance in hostile working conditions.
Incoloy 800/800H/800HT Valves consist mainly of Nickel (30–35%), Iron (39.5% min), Chromium (19–23%), with minor additions of Aluminum (0.15–0.60%), Titanium (0.15–0.60%), and Carbon (up to 0.10% for 800HT). These alloys have very good mechanical properties, such as tensile strength of 520–600 MPa, yield strength of 205–270 MPa, and elongation of 30–45%. Their physical properties are a density of 7.94 g/cm³ and a melting point of about 1350–1400°C. These valves have better resistance to oxidation, carburization, and high-temperature corrosion and hence are best suited for applications at elevated temperatures.
| Material | Incoloy |
|---|---|
| Seal Material | PTFE/ RPTFE |
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever DN350-DN1200 gear box |
| Operation Temperature | -10°C~150°C |
| Grade | Ni | Fe | Cr | Cu | Mn | S | Si | Ti | Al | C |
| Alloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .1 max |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .25-.60 | .85-1.20 | .06-.10 max |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .05-.10 max |
| Density | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Elongation |
| 7.94 g/cm3 | Psi – 30,000 , MPa – 205 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | 30 – 35 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Valves find extensive application in heat treatment equipment, petrochemical processing, nuclear steam generator tubing, and power generation plants, particularly in high-pressure and temperature systems. They are ideal for valve components in reformers, superheaters, and furnace applications and provide superior performance in thermal cycling and oxidation service environments. Their resistance to sulfidation, intergranular corrosion, and creep deformation makes them durable enough for long-term operation. These valves provide accurate flow control and long life, making them a good fit for refinery critical systems, chemical plants, and energy industry applications operating under severe service conditions.
