Jyoti Steels, a well-known Indian Mumbai-based manufacturer and supplier of premium Incoloy 825 Valves, caters to crucial industrial markets with corrosion-resistance and long-lasting flow control solutions. Supported by state-of-the-art manufacturing processes and rigorous quality checks, Jyoti Steels guarantees its Incoloy 825 valves to international standards of performance and reliability. Incoloy 825 valves are designed to function in harsh chemical, marine, and high-temperature applications, providing reliable operation and lifespan. With customer-driven philosophy, Jyoti Steels provides stringent applications in the chemical, oil & gas, and marine sectors.
Incoloy 825 Valves comprise Nickel (38–46%), Iron (balance, minimum 22%), Chromium (19.5–23.5%), Molybdenum (2.5–3.5%), Copper (1.5–3%), and Titanium (0.6–1.2%), with traces of Carbon (max 0.05%) and Manganese (max 1%). These valves possess outstanding mechanical properties like tensile strength of 690 MPa, yield strength of 275 MPa, and elongation of 30%. Physical properties involve density of 8.14 g/cm³, melting point of ~1370°C, and good oxidation resistance, pitting, crevice corrosion, and stress corrosion cracking resistance in both acidic as well as in chloride environments.
| Material | Incoloy |
|---|---|
| Seal Material | PTFE/ RPTFE |
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever DN350-DN1200 gear box |
| Operation Temperature | -10°C~150°C |
| Grade | Ni | Fe | Cr | Cu | Mn | S | Si | Ti | Al | C |
| Alloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .1 max |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .25-.60 | .85-1.20 | .06-.10 max |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .05-.10 max |
| Density | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Elongation |
| 7.94 g/cm3 | Psi – 30,000 , MPa – 205 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | 30 – 35 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Valves find widespread application in chemical processing, pollution control systems, marine service, offshore drilling for oil, and acid production units where corrosion resistance is critical. The valves are well suited to acid handling systems, heat exchangers, piping in sulfuric and phosphoric acid service, and waste treatment systems. Their resistance to reducing and oxidizing acids and the mechanical integrity under pressure and extreme temperatures make them the optimal choice for demanding flow regulation applications in aggressive industrial environments, guaranteeing safe and efficient process control over extended operational lifetimes.
