Jyoti Steels of Mumbai, India is a well-known producer and distributor of Incoloy 800/800H/800HT Bars of high quality for various industrial sectors that demand superior strength and resistance to heat. Working with a focus on excellence and in accordance with international standards, Jyoti Steels provides bars that provide superior durability and functionality in corrosive and high-temperature conditions. These bars have extensive application in petrochemical, power plant, thermal treatment, and chemical processing industries, where they are required to be highly resistant to mechanical strength, oxidation, and metallurgical stability.
Incoloy 800/800H/800HT Bars contain as the major element Nickel (30–35%), Iron (remainder), Chromium (19–23%), Carbon (up to 0.10% in case of 800HT), Aluminum (0.15–0.60%), and Titanium (0.15–0.60%). They have high mechanical properties such as tensile strength of around 600 MPa, yield strength of 275 MPa, and elongation of 30%. Their physical properties consist of a density of 7.94 g/cm³ and a melting range of 1357°C to 1385°C. These bars show great oxidation, sulfidation, and carburization resistance, hence being very suitable for exposure in harsh conditions over a long time at high temperatures.
| Specifications | : | AMS 5766 |
| Dimensions | : | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Length | : | 100 mm TO 6000 mm |
| Diameter | : | 10 mm To 100 mm |
| Specialize | : | Filler Wire, Coil Wire |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Wire in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Bars find applications in numerous applications such as heat exchangers, pressure vessels, furnace parts, steam generators, petrochemical process equipment, and nuclear power plants. Their superior resistance to creep rupture, thermal fatigue, and oxidizing and reducing environments makes them useful in chemical plants, refineries, power plants, and aerospace components. These bars are suited for applications where stability in extreme thermal and mechanical loading is needed to provide consistent service and long life operation in severe industrial applications.
