Jyoti Steels, a leading Mumbai, India-based manufacturer and supplier of superior quality Incoloy 825 Tubing, provides trustworthy solutions for industries working in corrosive and high-temperature conditions. With an unrelenting pursuit of excellence, Jyoti Steels supplies tubing that complies with international quality standards, providing durability, accuracy, and long-term performance. Its Incoloy 825 tubing enjoys broad usage across crucial applications such as chemical processing, marine work, and the oil and gas industries because it exhibits exceptional corrosion resistance, stress cracking, and oxidation resistance within acidic and aqueous environments.
Incoloy 825 Tubing consists of Nickel (38–46%), Iron (balance, minimum 22%), Chromium (19.5–23.5%), Molybdenum (2.5–3.5%), Copper (1.5–3%), and Titanium (0.6–1.2%), along with trace contents of Carbon (max 0.05%), Manganese (max 1%), and Silicon (max 0.5%). It possesses good mechanical properties like tensile strength of 690 MPa, yield strength of 275 MPa, and elongation of 30%. It possesses a melting range of 1370-1400°C and a physical density of 8.14 g/cm³ with outstanding acid corrosion resistance, oxidation, as well as stress corrosion cracking resulting from chlorides.
| Standard | ASTM B423, B705 / ASME SB 423, SB 705 |
| Standard | ASTM, ASME and API |
| Size | 15 NB UP TO 600 NB IN SCH 5S, 10S,10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 & XXS |
| Length | Single Random, Double Random & Required Length, Cut Length |
| End | Plain End, Beveled End, Treaded |
| Inconel 825 | Min |
| Ni | 38.0 – 46.0 |
| C | 0.05 max |
| Mn | 1.0 max |
| Si | 0.5 max |
| Cr | 19.5 – 23.5 |
| Fe | 22.0 min |
| Al | 0.2 max |
| Ti | 0.6 – 1.2 |
| cu | 1.5 – 3.0 |
| S | 0.015 max |
| Element | Inconel 825 |
| Density | 8.14 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 32,000 , MPa –220 |
| Elongation | 30 % |
| Hardness (Brinell) | – |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Tubing in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
