Jyoti Steels is a well-known manufacturer and supplier of Permalloy Sheets and Plates in Mumbai, India, providing high-quality magnetic alloy products designed for high-performance electrical and electronic uses. With outstanding magnetic permeability and low coercivity, our Permalloy sheets and plates are produced with accuracy to serve the needs of transformer cores, magnetic shielding, and sensitive instrumentation. With a keen emphasis on quality assurance, customization, and prompt delivery, Jyoti Steels caters to various industries in India and overseas and is a reputed supplier of high-grade magnetic materials.
Permalloy Sheets and Plates consist mostly of Nickel (78–80%) and Iron (20–22%), with minor additions of Molybdenum, Silicon, or Copper based on grade. This composition confers Permalloy its characteristic magnetic properties such as very high magnetic permeability and low coercivity. It possesses a density of about 8.7 g/cm³ and shows good ductility and moderate mechanical strength with a tensile strength of about 400–600 MPa and elongation of 30–50%. Permalloy also possesses low magnetostriction and high electrical resistivity and is therefore well suited for use in AC magnetic applications and electromagnetic interference shielding.
| Standard Specification : | |
| Dimensions : | – |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo | Fe |
| 1J50 | 0.010 | 0.17 | 0.35 | 0.006 | 0.005 | 49.80 | 0.02 | —— | Bal |
| 1J79 | 0.010 | 0.38 | 0.85 | 0.005 | 0.003 | 79.50 | 0.02 | 3.95 | Bal |
| 1J85 | 0.010 | 0.18 | 0.35 | 0.005 | 0.003 | 80.30 | 0.02 | 4.95 | Bal |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Permalloy Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Permalloy Sheets and Plates find extensive application in electrical and electronic sectors because of their exceptional magnetic characteristics. They find broad application in transformer cores, magnetic amplifiers, inductors, chokes, and relay cores. Owing to high permeability, they find good application as electromagnetic shielding for delicate instruments and electronic equipment. Permalloy is also employed in magnetic sensors, recording heads, and shield cabinets in defense and communication systems. Its high efficiency and low energy loss in magnetic flux conduction make it a critical requirement for precision and low magnetic interference applications, particularly in aerospace, medical devices, and power electronics industries.
