Home > Copper Nickel > Copper Nickel 70/30 Forged Fittings
Jyoti Steels is a reliable producer and seller of Copper Nickel 70/30 Forged Fittings in Mumbai, India. We are an expert in manufacturing high-quality forged fittings for a number of industries like marine, offshore, chemical, and petrochemical industries. Our Cu-Ni 70/30 Forged Fittings are preferred for their excellent corrosion resistance, strength, and performance in severe environments. With a dedication to excellence, we offer customized solutions meeting global standards, providing the reliability and durability of fittings for mission-critical applications in India and around the world.
Copper Nickel 70/30 Forged Fittings consist of 70% Copper and 30% Nickel, with small amounts of Iron (0.4–0.6%) and Manganese (0.4–1.0%) to enhance strength and corrosion resistance. These fittings provide tensile strength between 320 and 500 MPa, yield strength of 120–150 MPa, and elongation of 30–40%. They possess a density of around 8.95 g/cm³ and a melting range of 1170°C to 1240°C. With a proven record of withstanding seawater corrosion, stress corrosion cracking, and biofouling, these forged fittings also show high thermal conductivity and can thrive in high-pressure and aggressive environments.
| Specifications | : | ASTM B122, B171, B466, B467 |
| Size | : | 1/8” NB to 4” NB (Threaded Forged & Screwed-Forged) |
| Standards | : | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Class | : | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | : | Forged Fittings |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cupro Nickel 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 70/30 Forged Fittings have vast applications in marine, offshore, and industrial uses because of their excellent resistance against saltwater corrosion and high-strength characteristics. The fittings are used in seawater cooling systems, shipbuilding, ballast piping, and offshore oil drilling platforms. They are also utilized in desalination plants, heat exchangers, and chemical processing plants, where aggressive fluids and high temperatures are regularly encountered. The superior corrosion resistance of these forged fittings provides them with a solid alternative for critical applications, where they will achieve long-term performance even in hostile and high-moisture conditions.
