Jyoti Steels of Mumbai, India, is a reliable Copper Nickel Pipe manufacturer and supplier of high-quality Copper Nickel Pipes. Jyoti Steels has an excellent reputation for providing corrosion-resistant and high-performance piping solutions to industries like marine, offshore, power generation, and chemical processing. Jyoti Steels applies modern manufacturing techniques and rigorous quality inspections to guarantee that its Copper Nickel Pipes are of international standards. Celebrate for their strength, superior thermal conductivity, and seawater corrosion resistance, Jyoti Steels’ products are best known for reliability and long life in harsh environments.
Copper Nickel Pipes typically contain 90% Copper and 10% Nickel (Cu-Ni 90/10 grade) or 70% Copper and 30% Nickel (Cu-Ni 70/30 grade), along with minor amounts of Iron (1.5–2%) and Manganese (0.5–1%) to provide corrosion resistance and strength. These pipes provide tensile strength in the range of 350–500 MPa and yield strength of 100–150 MPa, with elongation of up to 30%. They have a physical density of 8.9 g/cm³, a melting temperature of approximately 1170°C, and superior thermal conductivity along with good biofouling and seawater corrosion resistance, which qualifies them for marine usage.
| Dimensions | : | ASTM, ASME and API |
|---|---|---|
| Standard | : | |
| Size | : | 1/8″NB TO 30″NB IN |
| Specialized in | : | Large Diameter Size |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Type | : | Seamless / Fabricated |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Threaded |
| Grade | Cu | Pb | Mn | Fe | Zn | Ni |
| Cu-Ni | 65.0 min | .05 max | 1.0 max | 0.4-1.0 | 1 max | 29 – 33 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| Density | kg/dm³ | 8.95 |
|---|---|---|
| Melting Range | °C | 1170-1240 |
| Specific Heat | J/kg °K | 377 |
| Thermal Conductivity | W/m°K | 29 |
| Coeff. of Linear Expansion 10-300°C” | 10-6/°K | 16 |
| Electrical Resistivity | microhm. cm | 34 |
| Modulus of Elasticity | GPa | 152 |
| Modulus of Rigidity | GPa | 56 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Pipes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Pipes find extensive application in industries requiring high corrosion resistance, particularly in marine and offshore environments. They are extensively used in seawater cooling systems, heat exchangers, condensers, ballast systems, and shipbuilding applications because of their resistance to biofouling and saltwater corrosion. In power generation, they are employed for feedwater heaters and evaporators. They also find applications in chemical processing, desalination plants, and firewater systems. Their thermal conductivity and mechanical integrity enable them to operate perfectly in high-temperature and high-pressure conditions, providing secure and effective fluid transfer in crucial systems.
