Home > Copper Nickel > Copper Nickel Coils
Mumbai, India-based Jyoti Steels is a renowned producer and supplier of high-quality Copper Nickel Coils. Renowned for their superior quality, excellent corrosion resistance, and durability, Jyoti Steels’ Copper Nickel Coils find extensive application in marine, power, and chemical industries. The company follows rigorous international quality standards and adopts cutting-edge manufacturing processes to supply products that provide consistent performance in demanding environments. Through its focus on customer satisfaction and technical proficiency, Jyoti Steels has created a strong reputation in both the domestic and international markets.
Copper Nickel Coils are generally fabricated from Cu-Ni 90/10 (90% Copper, 10% Nickel) or Cu-Ni 70/30 (70% Copper, 30% Nickel) alloys. They also include Iron (1.5–2%) and Manganese (up to 1%) to enhance mechanical strength and corrosion resistance. These coils provide tensile strength of 350–500 MPa and yield strength of 100–150 MPa, with elongation up to 30%. With a density of 8.9 g/cm³ and melting point at approximately 1170°C, they have superior thermal conductivity, high resistance to biofouling, and superior durability in saline and high-pressure applications.
| Grades | Copper Nickel Coils |
| Thickness | 0.1mmThk To 3 mm Thk |
| Width | 3.2mm To 1500mm |
| Length | AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Cupro Nickel SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Form | Coil / Strip |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Make | BAHRU, POSCO KOREA, POSCO THAINOX, COLUMBUS, ACERINOX, APERAM, TISCO, NISSHIN, NIPPON AND MANY MORE MILLS. |
| Grade | Cu | Pb | Fe | Zn | Mn | Ni+Co |
| C70400 | Balance | ≤ 0.05 | 1.3-1.7 | ≤ 1.0 | 0.3-0.8 | 4.8-6.2 |
| C70600 | Balance | ≤ 0.05 | 1.0-1.8 | ≤ 1.0 | ≤ 1.0 | 9.0-11.0 |
| C71000 | Balance | ≤ 0.05 | 0.5-1.0 | ≤ 1.0 | ≤ 1.0 | 19.0-23.0 |
| C71500 | Balance | ≤ 0.05 | 0.4-1.0 | ≤ 1.0 | ≤ 1.0 | 29.0-33.0 |
| Property | Units | 90-10 | 70-30 |
| Density | kg/dm3 | 8.90 | 8.95 |
| Melting point | °C | 1100-1145 | 1170-1240 |
| Specific heat | J/KGK | 377 | 377 |
| Thermal conductivity | W/mK | 50 | 29 |
| Linear expansion coefficient 10-300°C | 10-6/K | 17 | 16 |
| Electrical resistivity | Micro-ohm/cm | 19 | 34 |
| Modulus of elasticity | GPa | 135 | 152 |
| Modulus of rigidity | GPa | 50 | 56 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Coil in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Coils find extensive application in applications demanding superior corrosion resistance and thermal conductivity. They are used in condenser and heat exchanger tubing, seawater cooling, and offshore piping in the marine industry. They are utilized by power plants in feedwater heaters and evaporator systems. In chemical and petrochemical applications, they find use as process equipment components subject to aggressive fluids. Moreover, their non-magnetic nature and scaling resistance qualify them for medical, HVAC, and instrumentation applications. Their strength, flexibility, and long lifespan qualify them for both structural and fluid handling applications.
