Home > Copper Nickel > Copper Nickel Wire
Jyoti Steels is a prominent producer and distributor of high-performance Copper Nickel Wire in Mumbai, India. We offer high-quality wire solutions with specific specifications as per the severe requirements of marine, chemical, and electrical industries. Our Copper Nickel Wires are recognized for their superior corrosion resistance, thermal stability, and electrical conductivity. With state-of-the-art manufacturing techniques, strict quality control, and customer-oriented practices, Jyoti Steels provides stable and consistent products to customers in India and global markets, ensuring long-term stability in harsh environments.
Copper Nickel Wire usually has 90% Copper and 10% Nickel (Cu-Ni 90/10) or 70% Copper and 30% Nickel (Cu-Ni 70/30) with trace levels of Iron and Manganese for increased strength and corrosion resistance. The wire has a tensile strength of 350–550 MPa and yield strength of about 150 MPa, with elongation of up to 30%. It has a density of about 8.9 g/cm³ and melting point between 1170°C and 1240°C. These characteristics provide superior seawater corrosion, biofouling, and thermal shock resistance, thus ideal for marine and industrial use.
| Specifications | ASTM B206, ASME SB206 | |
|---|---|---|
| Copper Nickel Wire Grades | 90/10 Copper Nickel Wire, 70/30 Copper Nickel Wire (Cuni 90/10 & Cuni 70/30) | |
| Copper Nickel Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Copper Nickel Wire Length | 100 mm TO 6000 mm, customizable | |
| Copper Nickel Wire Diameter | 10 mm To 100 mm or as per client requirement | |
| Copper Nickel Wire Main Types |
| |
| Copper Nickel Wire Density | 8.89 g/cm3 | |
| 580-750 | |
| as standard | |
| 28-30 | |
| Surface | Polished bright, Smooth | |
| Copper Nickel Wire Technique | Cold Rolled, hot rolled | |
| Copper Nickel Wire Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Copper Nickel welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| Copper Nickel wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including: |
|
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70-30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 2260 F | 50000 psi | 20000 psi | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Wire in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Wire has extensive use in high corrosion resistance and thermal stability applications. In the shipbuilding sector, it finds widespread application in seawater piping, condensers, heat exchangers, and shipbuilding parts owing to its ability to resist biofouling and salinity. In electrical engineering, it is used as resistance wire and thermocouple components. It is also utilized in the production of brake lines, hydraulic systems, and instrumentation tubing in chemical and offshore industries. Its superior weldability and formability also make it suitable for use in HVAC systems, power generation, and coinage.
