Home > Copper Nickel > Copper Nickel 90/10 Fittings
Jyoti Steels is one of the pioneering manufacturers and exporters of high-quality Copper Nickel 90/10 Fittings in Mumbai, India. We offer corrosion-resistant, high-performance marine, offshore, chemical, and power industry piping components. We manufacture Cu-Ni 90/10 Fittings with careful precision to export them to any part of the world according to international standards so that they perform well and stay durable for longer periods of time. With sophisticated manufacturing facilities and a quality focus, Jyoti Steels offers dependable solutions to customers in India and overseas markets for corrosive and demanding conditions.
Copper Nickel 90/10 Fittings consist of about 90% Copper and 10% Nickel with minor additions of Iron (up to 1.5%) and Manganese (up to 1.0%) to increase strength and resistance against corrosion. Copper Nickel 90/10 Fittings provide a tensile strength of 275–400 MPa, yield strength of 100–150 MPa, and elongation up to 40%. The density is approximately 8.9 g/cm³, and the melting point is between 1100°C and 1145°C. Cu-Ni 90/10 fittings have high resistance to seawater corrosion, erosion, and biofouling, and also good thermal conductivity and moderate electrical conductivity, so they are very suitable for harsh operating conditions.
| Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Bending Radius | Radius=1 D, 2D, 3 D, 5D, 6D, 8 D, 10D |
| Grade | 90/10 |
| Size Range | Seamless Butt-Weld Fitting: From 1/2″ – 10″ Welded ButtWeld Fitting: From 1/2″ – 48″ |
| Dimension | ASME/ ANSI B16.9 | ASME B16.28 | MSS-SP-43 | BS1560 | BS4504 | BS10 |
| Size Ranges | ½” NB to 24″ NB in Schedule 10s, 40s, 80s, 160s, XXS. |
| Types | Welded | Seamless | Fabricated |
| Process of Manufacturing | Push, Press, Cast, Forge. |
| Thickness of Fitting | SCH10, SCH 20, SCH30, STD SCH40, SCH80, SCH60, XS, SCH100, SCH 120, SCH140, SCH 160, XXS available with NACE MR 01-75 |
| Grade | Fe | Ni | Cu | Pb | Mn | Zn |
| Cu-Ni 90-10 | 1.8 max | 9-11 max | 88.6 min | .05 max | 1.0 max | 1 max |
| Element | Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Copper Nickel 90/10 | 2260 F | 0.323 lb/in3 at 68 F | 20000 psi | 50000 psi | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 90/10 Fittings have widespread applications in marine and offshore engineering because of their excellent resistance to saltwater corrosion and biofouling. Typical applications are in seawater cooling systems, heat exchangers, condensers, shipbuilding pipelines, and ballast systems. In the petrochemical and chemical industries, they are employed in process piping, storage tanks, and pump systems. They also have applications in power generation, desalination plants, and HVAC systems. Their good weldability, mechanical properties, and corrosion resistance make them perfectly suitable for applications in fluid handling systems subject to high pressure, temperature, and corrosive or saline conditions.
