Jyoti Steels is a prominent Mumbai, India-based manufacturer and supplier of Copper Nickel 70/30 Flanges. With an impeccable reputation for providing long-lasting, high-performance products, we serve industries including marine, offshore, petrochemical, and power generation. Our Cu-Ni 70/30 Flanges are designed to precision for strength, corrosion resistance, and joint integrity in severe environments. Produced with premium materials and to international standards, Jyoti Steels delivers effective and durable flange solutions to customers throughout India and abroad.
Copper Nickel 70/30 Flanges consist of 70% Copper and 30% Nickel, with minor additions of Iron (0.4–0.6%) and Manganese (0.4–1.0%) for strength and corrosion resistance. These flanges provide tensile strength between 320–500 MPa, yield strength of 120–150 MPa, and elongation of 30–40%. Their density is about 8.95 g/cm³ and melting point is between 1170°C to 1240°C. Reputed for having good seawater corrosion resistance, stress cracking, and biofouling, these flanges also possess good thermal conductivity and are particularly suited for saline, high-temperature, and high-pressure operating conditions.
| Size | : | ½” to 12″ |
| Specification | : | ASTM / ASME SB 61 / 62 / 151 / 152. |
| Standard | : | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Class | : | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN. |
| Dimensions | : | ANSI/ASME B16.5, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Grades | : | UNS C71500 (CU -NI- 70/30) |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Copper Nickel 70/30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 0.323 lb/in3 at 68 F | 50000 psi | 20000 psi | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Flanges in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 70/30 Flanges find widespread applications in marine and offshore environments like seawater cooling systems, ship construction, firewater systems, and ballast lines. Due to their high resistance to chloride-induced corrosion and biofouling, they find extensive application for underwater and coastal pipeline couplings. In petrochemical and chemical industries, they are utilized to join piping systems conveying aggressive fluids. These flanges are also used in heat exchangers, desalination systems, and power generation equipment, providing safe sealing under very high temperature and pressure. Their resistance to corrosion, easy weldability, and long-term durability make them a vital part of fluid transport and structural systems.
