Mumbai, India-based Jyoti Steels is a world-famous Copper Nickel 70/30 Sheet and Plate manufacturer and supplier with a reputation for supplying high-quality products to several industries. Precision and durability committed, Jyoti Steels supplies Copper Nickel 70/30 sheets and plates that possess great corrosion resistance, particularly in chemical and marine environments. The company strictly adheres to international standards and serves industries including shipbuilding, offshore oil rigs, heat exchangers, and desalination plants with customized sizes and specifications to address both domestic as well as international customer needs.
Copper Nickel 70/30 Sheet and Plate has nearly 70% Copper and 30% Nickel with minor additions of Iron (0.4–1.0%) and Manganese (0.5–1.0%) for increased corrosion resistance and strength. This alloy offers high mechanical properties with 320–500 MPa tensile strength, approximately 130–250 MPa yield strength, and elongation of 30–45%. Its density is 8.9 g/cm³ and its melting point is approximately 1170°C. It possesses satisfactory thermal conductivity (~50 W/m·K) and electrical conductivity of the order 5–8% IACS and thus is very dependable for heat and corrosion-critical applications.
| UNS C71500 Plate Specification | MSRR, AMS, BS, ASTM B122 / ASTM B171 |
|---|---|
| Cuni 70/30 Plate Sizes (mm) | 1000 x 2000, 1220 x 2440, 1500 x 3000, 2000 x 2000, 2000 x 4000 |
| C71500 Cupro Alloy Plate Thickness | 0.1 to 100 mm Thk |
| Din 2.0882 70 30 CuNi Plate Width | 10-2500mm |
| ASTM B122 C71500 CDA 715 Plate Length | 2m, 2.44m, 3m, or as required |
| C71500 cuni Sheet AMS | AMS |
| Cu-Ni UNS C71500 70/30 Plate Finish | HR, CR, 2B, 2D, BA, NO(8), SATIN |
| ASTM B171 UNS C71500 Sheet Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Copper Nickel 70/30 Plate Stock in form of |
Coils, Checker, Circle, hot-rolled, Clad, annealed, Shim, Sheet, descaled, cold-rolled, Rolling, Rolls, Flat, sheared, Blank, Tread, Foils, Strip, Flats, Plate, soft-annealed, |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cupro Nickel 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 70/30 Sheet and Plate finds extensive applications in marine engineering owing to its exceptional resistance to corrosion by seawater, biofouling, and stress corrosion cracking. It is well suited for fabrication of condenser tubes, heat exchangers, seawater pipework, and marine hardware. In the field of power generation, it is applied for cooling circuits and desalination plants. Chemical processing industries make use of it for its strength in corrosive environments. Its high mechanical stability and thermal conduction also position it for application in offshore oil and gas platforms, hydraulic tubes, and all architectural and structural uses that call for long-duration durability.
