Jyoti Steels is a prominent Copper Nickel Sheet and Plate manufacturer and supplier located in Mumbai, India. Jyoti Steels is well-known for providing superior quality non-ferrous metal products and deals with copper-nickel alloys that possess higher corrosion resistance, durability, and superior formability. These sheets and plates are made with accuracy to international standards and are supplied to industries including marine, power generation, shipbuilding, and chemical processing. With an emphasis on quality and customer satisfaction, Jyoti Steels is a trusted source for Copper Nickel Sheet and Plates in international markets.
Copper Nickel Sheet and Plates are generally made of 90% Copper and 10% Nickel with minor additions of Iron (1.8%) and Manganese (1%) to provide better mechanical strength and resistance to corrosion. These alloys have tensile strength between 275–345 MPa and yield strength of about 105 MPa, with elongation of up to 30–40%. They are physically characterized by a density of 8.9 g/cm³ and a melting point of around 1100–1145°C. Their low electrical conductivity (10–12% IACS) and high thermal stability render them apt for use in seawater-exposed environments, high-pressure environments, and cyclic temperature environments.
Dimensions : ASTM, ASME and API
Standard :ASTM / ASME SB 171, SB 151
Size : 1 mm to 100 mm
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Length : Single Random, Double Random & Cut Length
| Grade | Cu | Mn | Pb | Fe | Zn | Ni |
| Cupro Nickel 90/10 | 88.6 min | 1.0 max | .05 max | 1.8 max | 1 max | 9-11 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Cu-Ni 90/10 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Sheets and Plates find very widespread use in seawater and offshore industry applications because of their exceptional resistance against seawater corrosion and biofouling. They are suitable for use in shipbuilding fittings, hulls, condensers, seawater plants, and piping systems for seawater. They are also used in heat exchangers, chemical processing plants, and cryogenic use. Their high mechanical properties, good fabricability, and resistance to stress corrosion cracking qualify them for industrial applications where strength and protection against corrosion are essential. These qualities provide long service life and low maintenance in harsh operating conditions.
